| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A10_123T17_9000005018_35045cztM0_level2.evt | modeM0/AS1A10_123T17_9000005018_35045cztM0_level2_quad_clean.evt |
| Size (bytes) | 191,013,120 | 49,656,960 |
| Size | 182.2 MB | 47.4 MB |
| Events in quadrant A | 1,162,378 | 340,732 |
| Events in quadrant B | 1,269,022 | 344,753 |
| Events in quadrant C | 1,283,581 | 343,997 |
| Events in quadrant D | 1,919,966 | 316,429 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 4871 | 1 |
| B | 0 | 5127 | 1 |
| C | 0 | 5162 | 1 |
| D | 0 | 7291 | 1 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 42 | 0 |
| B | 0 | 42 | 0 |
| C | 0 | 42 | 0 |
| D | 0 | 42 | 0 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 2 | 0 |
| B | 0 | 2 | 0 |
| C | 0 | 2 | 0 |
| D | 0 | 3 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 2185 | 4 | 0.183066% |
| B | 2185 | 28 | 1.281465% |
| C | 2185 | 22 | 1.006865% |
| D | 2185 | 83 | 3.798627% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 2185 | 2185 | 0 | 0 | 0.00% | 0.00% |  |
| B | 2185 | 2185 | 23 | 23 | 1.05% | 1.05% |  |
| C | 2185 | 2185 | 12 | 12 | 0.55% | 0.55% |  |
| D | 2185 | 2185 | 73 | 73 | 3.34% | 3.34% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 10 | 83 | 36705 | 642.7 | 282 | 278 | 56.7 |
| A | 15 | 169 | 23431 | 408.5 | 282 | 278 | 56.7 |
| A | 13 | 6 | 7346 | 124.7 | 282 | 278 | 56.7 |
| B | 5 | 172 | 140737 | 2629.55 | 279 | 272 | 53.4 |
| B | 0 | 190 | 20326 | 375.42 | 279 | 272 | 53.4 |
| B | 4 | 232 | 12249 | 224.21 | 279 | 272 | 53.4 |
| C | 15 | 214 | 92604 | 1407.1 | 284 | 287 | 65.6 |
| C | 0 | 10 | 72393 | 1099.04 | 284 | 287 | 65.6 |
| C | 14 | 67 | 6696 | 97.69 | 284 | 287 | 65.6 |
| D | 8 | 195 | 467258 | 6734.65 | 280 | 273 | 69.3 |
| D | 5 | 223 | 143559 | 2066.41 | 280 | 273 | 69.3 |
| D | 12 | 227 | 75614 | 1086.53 | 280 | 273 | 69.3 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
