| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1T05_015T01_9000005026_35106cztM0_level2.evt | modeM0/AS1T05_015T01_9000005026_35106cztM0_level2_quad_clean.evt |
| Size (bytes) | 535,461,120 | 87,776,640 |
| Size | 510.7 MB | 83.7 MB |
| Events in quadrant A | 4,842,243 | 541,883 |
| Events in quadrant B | 2,910,548 | 597,415 |
| Events in quadrant C | 2,933,392 | 592,979 |
| Events in quadrant D | 5,171,824 | 554,687 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 108 | 0 |
| B | 0 | 108 | 0 |
| C | 0 | 108 | 0 |
| D | 0 | 108 | 0 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 25 | 0 |
| B | 0 | 25 | 0 |
| C | 0 | 25 | 0 |
| D | 0 | 26 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 18099 | 3 |
| B | 0 | 12041 | 2 |
| C | 0 | 11751 | 2 |
| D | 0 | 19190 | 2 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 5298 | 740 | 13.967535% |
| B | 5298 | 56 | 1.057003% |
| C | 5298 | 120 | 2.265006% |
| D | 5298 | 85 | 1.604379% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7000 | 5299 | 590 | 590 | 8.43% | 11.13% |  |
| B | 7000 | 5299 | 29 | 29 | 0.41% | 0.55% |  |
| C | 7000 | 5299 | 79 | 79 | 1.13% | 1.49% |  |
| D | 7000 | 5299 | 56 | 56 | 0.80% | 1.06% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 15 | 169 | 2508515 | 21205.93 | 580 | 569 | 118.3 |
| A | 10 | 83 | 78137 | 655.88 | 580 | 569 | 118.3 |
| A | 13 | 6 | 9355 | 74.29 | 580 | 569 | 118.3 |
| B | 5 | 172 | 194838 | 1652.4 | 616 | 599 | 117.5 |
| B | 0 | 189 | 75889 | 640.5 | 616 | 599 | 117.5 |
| B | 5 | 255 | 64424 | 542.96 | 616 | 599 | 117.5 |
| C | 0 | 10 | 298488 | 2118.77 | 606 | 610 | 140.6 |
| C | 15 | 214 | 219074 | 1553.91 | 606 | 610 | 140.6 |
| C | 12 | 250 | 23997 | 166.35 | 606 | 610 | 140.6 |
| D | 8 | 195 | 2538841 | 17320.55 | 602 | 585 | 146.5 |
| D | 2 | 250 | 75281 | 509.71 | 602 | 585 | 146.5 |
| D | 13 | 249 | 47104 | 317.43 | 602 | 585 | 146.5 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
