| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A11_069T01_9000005034_35150cztM0_level2.evt | modeM0/AS1A11_069T01_9000005034_35150cztM0_level2_quad_clean.evt |
| Size (bytes) | 631,912,320 | 66,044,160 |
| Size | 602.6 MB | 63.0 MB |
| Events in quadrant A | 4,577,284 | 403,878 |
| Events in quadrant B | 5,915,597 | 384,785 |
| Events in quadrant C | 3,086,366 | 421,483 |
| Events in quadrant D | 5,179,768 | 396,923 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 17626 | 3 |
| B | 0 | 21373 | 2 |
| C | 0 | 12475 | 2 |
| D | 0 | 19382 | 2 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 27 | 0 |
| B | 0 | 27 | 0 |
| C | 0 | 27 | 0 |
| D | 0 | 28 | 0 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 114 | 0 |
| B | 0 | 114 | 0 |
| C | 0 | 114 | 0 |
| D | 0 | 114 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 5604 | 482 | 8.600999% |
| B | 5604 | 1100 | 19.628837% |
| C | 5604 | 103 | 1.837973% |
| D | 5604 | 235 | 4.193433% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7097 | 5605 | 318 | 318 | 4.48% | 5.67% |  |
| B | 7096 | 5604 | 695 | 695 | 9.79% | 12.40% |  |
| C | 7097 | 5605 | 76 | 76 | 1.07% | 1.36% |  |
| D | 7097 | 5605 | 268 | 268 | 3.78% | 4.78% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 15 | 169 | 2003567 | 15497.38 | 633 | 621 | 129.2 |
| A | 10 | 83 | 82592 | 634.23 | 633 | 621 | 129.2 |
| A | 9 | 143 | 27839 | 210.59 | 633 | 621 | 129.2 |
| B | 5 | 236 | 3202199 | 27818.17 | 599 | 584 | 115.1 |
| B | 5 | 172 | 254439 | 2205.69 | 599 | 584 | 115.1 |
| B | 4 | 232 | 64530 | 555.61 | 599 | 584 | 115.1 |
| C | 0 | 10 | 322674 | 2169.91 | 635 | 641 | 148.4 |
| C | 15 | 214 | 233479 | 1568.9 | 635 | 641 | 148.4 |
| C | 8 | 111 | 18980 | 123.57 | 635 | 641 | 148.4 |
| D | 8 | 195 | 1565596 | 10063.08 | 631 | 614 | 155.5 |
| D | 5 | 223 | 395373 | 2538.36 | 631 | 614 | 155.5 |
| D | 13 | 249 | 256211 | 1643.53 | 631 | 614 | 155.5 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
