| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A11_069T01_9000005034_35155cztM0_level2.evt | modeM0/AS1A11_069T01_9000005034_35155cztM0_level2_quad_clean.evt |
| Size (bytes) | 238,731,840 | 20,563,200 |
| Size | 227.7 MB | 19.6 MB |
| Events in quadrant A | 994,492 | 132,902 |
| Events in quadrant B | 2,764,586 | 96,226 |
| Events in quadrant C | 1,319,413 | 126,988 |
| Events in quadrant D | 2,010,891 | 117,260 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 4314 | 1 |
| B | 0 | 9596 | 1 |
| C | 0 | 5210 | 1 |
| D | 0 | 7409 | 1 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 13 | 0 |
| B | 0 | 13 | 0 |
| C | 0 | 13 | 0 |
| D | 0 | 13 | 0 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 42 | 0 |
| B | 0 | 42 | 0 |
| C | 0 | 42 | 0 |
| D | 0 | 42 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 2046 | 5 | 0.244379% |
| B | 2046 | 748 | 36.559140% |
| C | 2046 | 94 | 4.594330% |
| D | 2046 | 192 | 9.384164% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 3329 | 2047 | 1 | 1 | 0.03% | 0.05% |  |
| B | 3329 | 2047 | 509 | 509 | 15.29% | 24.87% |  |
| C | 3329 | 2047 | 85 | 85 | 2.55% | 4.15% |  |
| D | 3329 | 2047 | 148 | 148 | 4.45% | 7.23% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 10 | 83 | 42278 | 861.19 | 232 | 227 | 48.8 |
| A | 9 | 143 | 32753 | 666.12 | 232 | 227 | 48.8 |
| A | 15 | 169 | 9959 | 199.31 | 232 | 227 | 48.8 |
| B | 5 | 236 | 1962166 | 49284.48 | 195 | 190 | 39.8 |
| B | 5 | 172 | 30186 | 753.49 | 195 | 190 | 39.8 |
| B | 12 | 111 | 4720 | 113.79 | 195 | 190 | 39.8 |
| C | 0 | 207 | 213462 | 3888.87 | 225 | 227 | 54.8 |
| C | 0 | 10 | 135421 | 2465.6 | 225 | 227 | 54.8 |
| C | 15 | 214 | 86031 | 1564.85 | 225 | 227 | 54.8 |
| D | 8 | 195 | 678554 | 12119.09 | 220 | 213 | 56.0 |
| D | 13 | 249 | 154170 | 2750.56 | 220 | 213 | 56.0 |
| D | 7 | 80 | 84811 | 1511.41 | 220 | 213 | 56.0 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
