| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1C07_001T06_9000005046_35179cztM0_level2.evt | modeM0/AS1C07_001T06_9000005046_35179cztM0_level2_quad_clean.evt |
| Size (bytes) | 819,630,720 | 98,346,240 |
| Size | 781.7 MB | 93.8 MB |
| Events in quadrant A | 2,650,136 | 708,998 |
| Events in quadrant B | 9,577,946 | 540,517 |
| Events in quadrant C | 3,096,981 | 722,222 |
| Events in quadrant D | 9,117,657 | 610,284 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 114 | 0 |
| B | 0 | 114 | 0 |
| C | 0 | 114 | 0 |
| D | 0 | 114 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 11678 | 3 |
| B | 0 | 32376 | 2 |
| C | 0 | 12705 | 2 |
| D | 0 | 31028 | 2 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 21 | 0 |
| B | 0 | 21 | 0 |
| C | 0 | 21 | 0 |
| D | 0 | 22 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 5642 | 15 | 0.265863% |
| B | 5642 | 2765 | 49.007444% |
| C | 5642 | 97 | 1.719248% |
| D | 5642 | 1617 | 28.660050% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7135 | 5643 | 6 | 6 | 0.08% | 0.11% |  |
| B | 7135 | 5643 | 2044 | 2044 | 28.65% | 36.22% |  |
| C | 7135 | 5643 | 74 | 74 | 1.04% | 1.31% |  |
| D | 7135 | 5643 | 1657 | 1657 | 23.22% | 29.36% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 10 | 83 | 102839 | 810.93 | 629 | 618 | 126.1 |
| A | 9 | 143 | 34245 | 266.77 | 629 | 618 | 126.1 |
| A | 12 | 16 | 29545 | 229.48 | 629 | 618 | 126.1 |
| B | 5 | 236 | 7138305 | 75494.68 | 499 | 487 | 94.5 |
| B | 5 | 172 | 343237 | 3625.17 | 499 | 487 | 94.5 |
| B | 3 | 112 | 76243 | 801.25 | 499 | 487 | 94.5 |
| C | 0 | 10 | 250376 | 1745.83 | 620 | 622 | 143.1 |
| C | 15 | 214 | 235650 | 1642.89 | 620 | 622 | 143.1 |
| C | 1 | 23 | 91937 | 638.31 | 620 | 622 | 143.1 |
| D | 8 | 195 | 5898800 | 38483.92 | 571 | 559 | 153.3 |
| D | 8 | 230 | 281927 | 1835.83 | 571 | 559 | 153.3 |
| D | 13 | 249 | 268707 | 1749.57 | 571 | 559 | 153.3 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
