| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1C07_004T01_9000005052_35203cztM0_level2.evt | modeM0/AS1C07_004T01_9000005052_35203cztM0_level2_quad_clean.evt |
| Size (bytes) | 689,207,040 | 96,033,600 |
| Size | 657.3 MB | 91.6 MB |
| Events in quadrant A | 3,893,862 | 653,842 |
| Events in quadrant B | 5,409,480 | 634,714 |
| Events in quadrant C | 3,184,988 | 670,643 |
| Events in quadrant D | 8,045,493 | 595,333 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 14883 | 3 |
| B | 0 | 19503 | 2 |
| C | 0 | 12602 | 2 |
| D | 0 | 27443 | 2 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 102 | 0 |
| B | 0 | 102 | 0 |
| C | 0 | 102 | 0 |
| D | 0 | 102 | 0 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 29 | 0 |
| B | 0 | 29 | 0 |
| C | 0 | 29 | 0 |
| D | 0 | 30 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 5042 | 312 | 6.188021% |
| B | 5042 | 927 | 18.385561% |
| C | 5042 | 162 | 3.213011% |
| D | 5042 | 610 | 12.098374% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7075 | 5043 | 217 | 217 | 3.07% | 4.30% |  |
| B | 7075 | 5043 | 571 | 571 | 8.07% | 11.32% |  |
| C | 7075 | 5043 | 118 | 118 | 1.67% | 2.34% |  |
| D | 7075 | 5043 | 922 | 922 | 13.03% | 18.28% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 14 | 250 | 1224942 | 9369.08 | 657 | 649 | 130.7 |
| A | 10 | 83 | 97612 | 742.02 | 657 | 649 | 130.7 |
| A | 13 | 6 | 14657 | 107.2 | 657 | 649 | 130.7 |
| B | 5 | 236 | 2685572 | 23046.6 | 617 | 604 | 116.5 |
| B | 3 | 112 | 201038 | 1720.44 | 617 | 604 | 116.5 |
| B | 4 | 232 | 31534 | 265.49 | 617 | 604 | 116.5 |
| C | 0 | 10 | 285463 | 1958.41 | 636 | 644 | 145.4 |
| C | 15 | 214 | 215084 | 1474.48 | 636 | 644 | 145.4 |
| C | 1 | 23 | 188210 | 1289.7 | 636 | 644 | 145.4 |
| D | 8 | 195 | 4825980 | 31462.82 | 633 | 617 | 153.4 |
| D | 13 | 249 | 140700 | 913.38 | 633 | 617 | 153.4 |
| D | 1 | 47 | 128648 | 834.8 | 633 | 617 | 153.4 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
