| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1T05_023T01_9000005058_35307cztM0_level2.evt | modeM0/AS1T05_023T01_9000005058_35307cztM0_level2_quad_clean.evt |
| Size (bytes) | 633,709,440 | 57,631,680 |
| Size | 604.4 MB | 55.0 MB |
| Events in quadrant A | 4,419,116 | 359,684 |
| Events in quadrant B | 7,369,997 | 307,274 |
| Events in quadrant C | 3,026,800 | 368,947 |
| Events in quadrant D | 4,026,998 | 346,262 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 16604 | 3 |
| B | 0 | 25466 | 2 |
| C | 0 | 11835 | 2 |
| D | 0 | 15441 | 2 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 32 | 0 |
| B | 0 | 32 | 0 |
| C | 0 | 32 | 0 |
| D | 0 | 33 | 0 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 104 | 0 |
| B | 0 | 104 | 0 |
| C | 0 | 104 | 0 |
| D | 0 | 104 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 5165 | 220 | 4.259439% |
| B | 5165 | 1883 | 36.456922% |
| C | 5165 | 134 | 2.594385% |
| D | 5165 | 215 | 4.162633% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7288 | 5166 | 228 | 228 | 3.13% | 4.41% |  |
| B | 7287 | 5165 | 1484 | 1484 | 20.37% | 28.73% |  |
| C | 7288 | 5166 | 97 | 97 | 1.33% | 1.88% |  |
| D | 7288 | 5166 | 201 | 201 | 2.76% | 3.89% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 15 | 169 | 1862895 | 14810.4 | 628 | 617 | 125.7 |
| A | 10 | 83 | 93293 | 737.04 | 628 | 617 | 125.7 |
| A | 13 | 6 | 14532 | 110.66 | 628 | 617 | 125.7 |
| B | 5 | 236 | 2895277 | 28529.6 | 538 | 525 | 101.5 |
| B | 5 | 172 | 2327782 | 22936.58 | 538 | 525 | 101.5 |
| B | 4 | 232 | 26472 | 255.72 | 538 | 525 | 101.5 |
| C | 0 | 10 | 406642 | 2927.11 | 603 | 609 | 138.7 |
| C | 15 | 214 | 214851 | 1544.48 | 603 | 609 | 138.7 |
| C | 3 | 233 | 42150 | 299.47 | 603 | 609 | 138.7 |
| D | 12 | 235 | 485316 | 3331.08 | 606 | 590 | 145.5 |
| D | 8 | 195 | 350625 | 2405.47 | 606 | 590 | 145.5 |
| D | 7 | 80 | 305489 | 2095.29 | 606 | 590 | 145.5 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
