| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A11_093T01_9000005064_35339cztM0_level2.evt | modeM0/AS1A11_093T01_9000005064_35339cztM0_level2_quad_clean.evt |
| Size (bytes) | 620,144,640 | 68,855,040 |
| Size | 591.4 MB | 65.7 MB |
| Events in quadrant A | 2,783,800 | 445,930 |
| Events in quadrant B | 7,937,053 | 354,084 |
| Events in quadrant C | 3,071,096 | 456,780 |
| Events in quadrant D | 4,599,652 | 425,263 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 12073 | 3 |
| B | 0 | 27554 | 2 |
| C | 0 | 12534 | 2 |
| D | 0 | 17639 | 2 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 118 | 0 |
| B | 0 | 118 | 0 |
| C | 0 | 118 | 0 |
| D | 0 | 118 | 0 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 18 | 0 |
| B | 0 | 18 | 0 |
| C | 0 | 18 | 0 |
| D | 0 | 19 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 5749 | 30 | 0.521830% |
| B | 5749 | 2098 | 36.493303% |
| C | 5749 | 49 | 0.852322% |
| D | 5749 | 413 | 7.183858% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7091 | 5749 | 24 | 24 | 0.34% | 0.42% |  |
| B | 7091 | 5748 | 1706 | 1706 | 24.06% | 29.68% |  |
| C | 7091 | 5748 | 37 | 37 | 0.52% | 0.64% |  |
| D | 7091 | 5748 | 373 | 373 | 5.26% | 6.49% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 10 | 83 | 111298 | 840.22 | 654 | 641 | 131.7 |
| A | 9 | 143 | 43251 | 323.54 | 654 | 641 | 131.7 |
| A | 8 | 192 | 43094 | 322.35 | 654 | 641 | 131.7 |
| B | 5 | 236 | 3267279 | 31602.92 | 538 | 524 | 103.4 |
| B | 5 | 172 | 2483691 | 24022.41 | 538 | 524 | 103.4 |
| B | 4 | 232 | 26382 | 250.15 | 538 | 524 | 103.4 |
| C | 15 | 214 | 240889 | 1618.14 | 640 | 644 | 148.5 |
| C | 0 | 10 | 204648 | 1374.05 | 640 | 644 | 148.5 |
| C | 4 | 254 | 83909 | 560.82 | 640 | 644 | 148.5 |
| D | 10 | 118 | 597070 | 3946.81 | 620 | 602 | 151.1 |
| D | 8 | 195 | 519471 | 3433.34 | 620 | 602 | 151.1 |
| D | 2 | 250 | 379230 | 2505.37 | 620 | 602 | 151.1 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
