| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A11_093T01_9000005064_35343cztM0_level2.evt | modeM0/AS1A11_093T01_9000005064_35343cztM0_level2_quad_clean.evt |
| Size (bytes) | 1,041,206,400 | 206,199,360 |
| Size | 993.0 MB | 196.6 MB |
| Events in quadrant A | 5,899,913 | 1,351,623 |
| Events in quadrant B | 9,436,094 | 1,322,826 |
| Events in quadrant C | 7,213,280 | 1,401,619 |
| Events in quadrant D | 8,127,473 | 1,292,946 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 26178 | 4 |
| B | 0 | 36489 | 3 |
| C | 0 | 29414 | 3 |
| D | 0 | 32679 | 3 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 258 | 0 |
| B | 0 | 258 | 0 |
| C | 0 | 258 | 0 |
| D | 0 | 258 | 0 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 44 | 0 |
| B | 0 | 44 | 0 |
| C | 0 | 44 | 0 |
| D | 0 | 44 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 12677 | 47 | 0.370750% |
| B | 12677 | 1152 | 9.087323% |
| C | 12677 | 183 | 1.443559% |
| D | 12677 | 488 | 3.849491% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 17004 | 12680 | 22 | 22 | 0.13% | 0.17% |  |
| B | 17004 | 12679 | 985 | 985 | 5.79% | 7.77% |  |
| C | 17004 | 12679 | 130 | 130 | 0.76% | 1.03% |  |
| D | 17004 | 12679 | 410 | 410 | 2.41% | 3.23% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 10 | 83 | 189471 | 651.15 | 1434 | 1406 | 288.8 |
| A | 8 | 192 | 54121 | 182.52 | 1434 | 1406 | 288.8 |
| A | 9 | 143 | 49847 | 167.72 | 1434 | 1406 | 288.8 |
| B | 5 | 172 | 1967287 | 7399.22 | 1387 | 1349 | 265.7 |
| B | 5 | 236 | 1871319 | 7038.03 | 1387 | 1349 | 265.7 |
| B | 4 | 232 | 78717 | 291.19 | 1387 | 1349 | 265.7 |
| C | 0 | 10 | 533800 | 1646.3 | 1405 | 1420 | 323.4 |
| C | 15 | 214 | 513803 | 1584.46 | 1405 | 1420 | 323.4 |
| C | 4 | 254 | 457308 | 1409.76 | 1405 | 1420 | 323.4 |
| D | 7 | 80 | 688644 | 2077.96 | 1370 | 1331 | 330.8 |
| D | 8 | 195 | 657259 | 1983.07 | 1370 | 1331 | 330.8 |
| D | 13 | 249 | 502787 | 1516.05 | 1370 | 1331 | 330.8 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
