| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1T05_022T01_9000005070_35400cztM0_level2.evt | modeM0/AS1T05_022T01_9000005070_35400cztM0_level2_quad_clean.evt |
| Size (bytes) | 381,372,480 | 31,697,280 |
| Size | 363.7 MB | 30.2 MB |
| Events in quadrant A | 1,310,296 | 228,132 |
| Events in quadrant B | 4,967,565 | 163,055 |
| Events in quadrant C | 1,553,369 | 226,224 |
| Events in quadrant D | 3,549,328 | 162,866 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 5341 | 2 |
| B | 0 | 16454 | 1 |
| C | 0 | 6017 | 1 |
| D | 0 | 12260 | 1 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 50 | 0 |
| B | 0 | 50 | 0 |
| C | 0 | 50 | 0 |
| D | 0 | 50 | 0 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 15 | 0 |
| B | 0 | 15 | 0 |
| C | 0 | 15 | 0 |
| D | 0 | 15 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 2484 | 5 | 0.201288% |
| B | 2484 | 1648 | 66.344605% |
| C | 2484 | 81 | 3.260870% |
| D | 2484 | 994 | 40.016103% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 3947 | 2485 | 0 | 0 | 0.00% | 0.00% |  |
| B | 3947 | 2485 | 1355 | 1355 | 34.33% | 54.53% |  |
| C | 3947 | 2485 | 48 | 48 | 1.22% | 1.93% |  |
| D | 3947 | 2485 | 721 | 721 | 18.27% | 29.01% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 10 | 83 | 63161 | 973.77 | 309 | 303 | 64.6 |
| A | 9 | 143 | 40998 | 630.43 | 309 | 303 | 64.6 |
| A | 13 | 6 | 9206 | 137.92 | 309 | 303 | 64.6 |
| B | 4 | 251 | 1816050 | 43567.06 | 204 | 199 | 41.7 |
| B | 5 | 14 | 759468 | 18216.87 | 204 | 199 | 41.7 |
| B | 5 | 31 | 725708 | 17406.88 | 204 | 199 | 41.7 |
| C | 0 | 10 | 207749 | 2965.86 | 294 | 296 | 69.9 |
| C | 15 | 214 | 102580 | 1462.31 | 294 | 296 | 69.9 |
| C | 3 | 233 | 62432 | 888.33 | 294 | 296 | 69.9 |
| D | 7 | 80 | 2159385 | 36349.81 | 234 | 226 | 59.4 |
| D | 2 | 250 | 130121 | 2186.8 | 234 | 226 | 59.4 |
| D | 2 | 152 | 97284 | 1633.99 | 234 | 226 | 59.4 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
