| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A11_097T17_9000005074_35441cztM0_level2.evt | modeM0/AS1A11_097T17_9000005074_35441cztM0_level2_quad_clean.evt |
| Size (bytes) | 692,740,800 | 79,871,040 |
| Size | 660.6 MB | 76.2 MB |
| Events in quadrant A | 3,027,616 | 504,830 |
| Events in quadrant B | 8,401,974 | 482,911 |
| Events in quadrant C | 5,087,397 | 500,867 |
| Events in quadrant D | 4,030,853 | 483,324 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 27 | 0 |
| B | 0 | 27 | 0 |
| C | 0 | 27 | 0 |
| D | 0 | 27 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 13036 | 6 |
| B | 0 | 29532 | 11 |
| C | 0 | 19176 | 3 |
| D | 0 | 16192 | 7 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 132 | 0 |
| B | 0 | 132 | 0 |
| C | 0 | 132 | 0 |
| D | 0 | 132 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 6398 | 10 | 0.156299% |
| B | 6397 | 1055 | 16.492106% |
| C | 6399 | 506 | 7.907486% |
| D | 6396 | 208 | 3.252033% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 9087 | 6401 | 0 | 0 | 0.00% | 0.00% |  |
| B | 9087 | 6401 | 590 | 590 | 6.49% | 9.22% |  |
| C | 9087 | 6402 | 342 | 342 | 3.76% | 5.34% |  |
| D | 9087 | 6401 | 152 | 152 | 1.67% | 2.37% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 10 | 83 | 133363 | 883.92 | 743 | 725 | 150.1 |
| A | 13 | 6 | 12428 | 77.99 | 743 | 725 | 150.1 |
| A | 8 | 6 | 12252 | 76.82 | 743 | 725 | 150.1 |
| B | 4 | 251 | 4765557 | 34514.84 | 711 | 693 | 138.1 |
| B | 5 | 236 | 381916 | 2761.43 | 711 | 693 | 138.1 |
| B | 5 | 200 | 213606 | 1542.26 | 711 | 693 | 138.1 |
| C | 4 | 254 | 1062672 | 6558.49 | 695 | 700 | 161.9 |
| C | 0 | 207 | 516063 | 3182.76 | 695 | 700 | 161.9 |
| C | 0 | 10 | 453082 | 2793.81 | 695 | 700 | 161.9 |
| D | 13 | 249 | 318801 | 1831.26 | 713 | 693 | 173.7 |
| D | 2 | 153 | 250136 | 1435.97 | 713 | 693 | 173.7 |
| D | 12 | 6 | 237217 | 1361.6 | 713 | 693 | 173.7 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
