| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A11_095T06_9000005078_35467cztM0_level2.evt | modeM0/AS1A11_095T06_9000005078_35467cztM0_level2_quad_clean.evt |
| Size (bytes) | 394,836,480 | 47,301,120 |
| Size | 376.5 MB | 45.1 MB |
| Events in quadrant A | 2,520,385 | 275,088 |
| Events in quadrant B | 2,565,939 | 281,282 |
| Events in quadrant C | 3,224,824 | 265,961 |
| Events in quadrant D | 3,301,014 | 253,273 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 32 | 0 |
| B | 0 | 32 | 0 |
| C | 0 | 32 | 0 |
| D | 0 | 33 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 10435 | 3 |
| B | 0 | 10686 | 2 |
| C | 0 | 12617 | 2 |
| D | 0 | 13025 | 2 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 104 | 0 |
| B | 0 | 104 | 0 |
| C | 0 | 104 | 0 |
| D | 0 | 104 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 5078 | 12 | 0.236314% |
| B | 5078 | 30 | 0.590784% |
| C | 5078 | 112 | 2.205593% |
| D | 5078 | 207 | 4.076408% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7051 | 5079 | 0 | 0 | 0.00% | 0.00% |  |
| B | 7051 | 5079 | 9 | 9 | 0.13% | 0.18% |  |
| C | 7051 | 5079 | 76 | 76 | 1.08% | 1.50% |  |
| D | 7051 | 5079 | 191 | 191 | 2.71% | 3.76% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 10 | 83 | 124873 | 1003.68 | 612 | 600 | 123.8 |
| A | 13 | 6 | 14962 | 115.99 | 612 | 600 | 123.8 |
| A | 15 | 169 | 12475 | 95.91 | 612 | 600 | 123.8 |
| B | 5 | 172 | 128606 | 1089.58 | 608 | 592 | 117.5 |
| B | 5 | 200 | 22510 | 186.55 | 608 | 592 | 117.5 |
| B | 12 | 111 | 14620 | 119.4 | 608 | 592 | 117.5 |
| C | 0 | 10 | 428117 | 3097.63 | 587 | 590 | 138.0 |
| C | 0 | 207 | 288122 | 2083.3 | 587 | 590 | 138.0 |
| C | 15 | 214 | 212674 | 1536.65 | 587 | 590 | 138.0 |
| D | 7 | 80 | 460059 | 3215.1 | 581 | 565 | 142.9 |
| D | 7 | 38 | 223598 | 1560.57 | 581 | 565 | 142.9 |
| D | 8 | 195 | 98310 | 683.93 | 581 | 565 | 142.9 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
