| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A11_097T22_9000005082_35497cztM0_level2.evt | modeM0/AS1A11_097T22_9000005082_35497cztM0_level2_quad_clean.evt |
| Size (bytes) | 379,630,080 | 67,757,760 |
| Size | 362.0 MB | 64.6 MB |
| Events in quadrant A | 2,478,047 | 417,179 |
| Events in quadrant B | 2,965,320 | 429,178 |
| Events in quadrant C | 2,936,210 | 431,560 |
| Events in quadrant D | 2,762,325 | 408,154 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 17 | 0 |
| B | 0 | 17 | 0 |
| C | 0 | 17 | 0 |
| D | 0 | 17 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 10753 | 2 |
| B | 0 | 12146 | 1 |
| C | 0 | 11902 | 1 |
| D | 0 | 11639 | 1 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 106 | 0 |
| B | 0 | 106 | 0 |
| C | 0 | 106 | 0 |
| D | 0 | 106 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 5221 | 5 | 0.095767% |
| B | 5221 | 132 | 2.528251% |
| C | 5221 | 71 | 1.359893% |
| D | 5221 | 56 | 1.072591% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 6864 | 5222 | 0 | 0 | 0.00% | 0.00% |  |
| B | 6864 | 5222 | 69 | 69 | 1.01% | 1.32% |  |
| C | 6864 | 5222 | 55 | 55 | 0.80% | 1.05% |  |
| D | 6864 | 5222 | 46 | 46 | 0.67% | 0.88% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 10 | 83 | 99515 | 817.01 | 593 | 581 | 121.1 |
| A | 7 | 3 | 52354 | 427.55 | 593 | 581 | 121.1 |
| A | 15 | 169 | 31117 | 252.17 | 593 | 581 | 121.1 |
| B | 5 | 172 | 256719 | 2273.42 | 587 | 570 | 112.7 |
| B | 4 | 232 | 176122 | 1558.09 | 587 | 570 | 112.7 |
| B | 5 | 236 | 161532 | 1428.6 | 587 | 570 | 112.7 |
| C | 0 | 207 | 271428 | 2020.0 | 578 | 581 | 134.1 |
| C | 15 | 214 | 215248 | 1601.0 | 578 | 581 | 134.1 |
| C | 0 | 10 | 151753 | 1127.45 | 578 | 581 | 134.1 |
| D | 7 | 223 | 151390 | 1081.99 | 578 | 563 | 139.4 |
| D | 8 | 195 | 98392 | 701.79 | 578 | 563 | 139.4 |
| D | 7 | 80 | 97174 | 693.06 | 578 | 563 | 139.4 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
