| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A11_097T09_9000005086_35536cztM0_level2.evt | modeM0/AS1A11_097T09_9000005086_35536cztM0_level2_quad_clean.evt |
| Size (bytes) | 411,474,240 | 67,728,960 |
| Size | 392.4 MB | 64.6 MB |
| Events in quadrant A | 2,550,510 | 434,256 |
| Events in quadrant B | 2,841,602 | 436,452 |
| Events in quadrant C | 3,077,580 | 425,810 |
| Events in quadrant D | 3,648,895 | 400,323 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 104 | 0 |
| B | 0 | 104 | 0 |
| C | 0 | 104 | 0 |
| D | 0 | 104 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 10656 | 3 |
| B | 0 | 11520 | 2 |
| C | 0 | 12156 | 2 |
| D | 0 | 14203 | 2 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 29 | 0 |
| B | 0 | 29 | 0 |
| C | 0 | 29 | 0 |
| D | 0 | 30 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 5043 | 6 | 0.118977% |
| B | 5043 | 116 | 2.300218% |
| C | 5043 | 107 | 2.121753% |
| D | 5043 | 159 | 3.152885% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7076 | 5044 | 0 | 0 | 0.00% | 0.00% |  |
| B | 7076 | 5044 | 77 | 77 | 1.09% | 1.53% |  |
| C | 7076 | 5044 | 81 | 81 | 1.14% | 1.61% |  |
| D | 7076 | 5044 | 155 | 155 | 2.19% | 3.07% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 10 | 83 | 129454 | 1030.06 | 622 | 612 | 125.1 |
| A | 15 | 169 | 14301 | 109.44 | 622 | 612 | 125.1 |
| A | 13 | 6 | 7864 | 57.98 | 622 | 612 | 125.1 |
| B | 5 | 236 | 251028 | 2149.37 | 615 | 601 | 116.5 |
| B | 5 | 172 | 115517 | 986.3 | 615 | 601 | 116.5 |
| B | 5 | 255 | 22082 | 184.37 | 615 | 601 | 116.5 |
| C | 0 | 10 | 382128 | 2733.43 | 603 | 609 | 139.6 |
| C | 15 | 214 | 227317 | 1624.27 | 603 | 609 | 139.6 |
| C | 0 | 207 | 68787 | 488.47 | 603 | 609 | 139.6 |
| D | 12 | 235 | 880268 | 6076.71 | 595 | 580 | 144.8 |
| D | 2 | 250 | 131920 | 907.27 | 595 | 580 | 144.8 |
| D | 8 | 195 | 109044 | 749.25 | 595 | 580 | 144.8 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
