| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A11_093T01_9000005090_35545cztM0_level2.evt | modeM0/AS1A11_093T01_9000005090_35545cztM0_level2_quad_clean.evt |
| Size (bytes) | 228,735,360 | 42,917,760 |
| Size | 218.1 MB | 40.9 MB |
| Events in quadrant A | 1,506,734 | 263,320 |
| Events in quadrant B | 1,580,974 | 271,580 |
| Events in quadrant C | 1,785,813 | 277,811 |
| Events in quadrant D | 1,838,184 | 262,763 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 64 | 0 |
| B | 0 | 64 | 0 |
| C | 0 | 64 | 0 |
| D | 0 | 64 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 6514 | 2 |
| B | 0 | 6690 | 1 |
| C | 0 | 7076 | 1 |
| D | 0 | 7367 | 1 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 15 | 0 |
| B | 0 | 15 | 0 |
| C | 0 | 15 | 0 |
| D | 0 | 15 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 3149 | 4 | 0.127024% |
| B | 3149 | 29 | 0.920927% |
| C | 3149 | 48 | 1.524293% |
| D | 3149 | 60 | 1.905367% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 4612 | 3150 | 1 | 1 | 0.02% | 0.03% |  |
| B | 4612 | 3150 | 19 | 19 | 0.41% | 0.60% |  |
| C | 4612 | 3150 | 39 | 39 | 0.85% | 1.24% |  |
| D | 4612 | 3150 | 45 | 45 | 0.98% | 1.43% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 10 | 83 | 74679 | 987.5 | 366 | 359 | 75.3 |
| A | 13 | 6 | 8398 | 106.82 | 366 | 359 | 75.3 |
| A | 9 | 143 | 6386 | 80.08 | 366 | 359 | 75.3 |
| B | 5 | 172 | 56383 | 771.71 | 365 | 354 | 72.6 |
| B | 5 | 200 | 42239 | 576.9 | 365 | 354 | 72.6 |
| B | 4 | 81 | 15490 | 208.47 | 365 | 354 | 72.6 |
| C | 0 | 10 | 166185 | 1955.73 | 358 | 360 | 84.8 |
| C | 15 | 214 | 140487 | 1652.65 | 358 | 360 | 84.8 |
| C | 0 | 239 | 53777 | 630.0 | 358 | 360 | 84.8 |
| D | 8 | 195 | 172870 | 1994.34 | 354 | 345 | 86.5 |
| D | 10 | 118 | 96304 | 1109.26 | 354 | 345 | 86.5 |
| D | 10 | 199 | 72878 | 838.46 | 354 | 345 | 86.5 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
