| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A11_093T01_9000005090_35556cztM0_level2.evt | modeM0/AS1A11_093T01_9000005090_35556cztM0_level2_quad_clean.evt |
| Size (bytes) | 449,907,840 | 78,197,760 |
| Size | 429.1 MB | 74.6 MB |
| Events in quadrant A | 3,007,348 | 479,434 |
| Events in quadrant B | 2,966,110 | 497,991 |
| Events in quadrant C | 3,224,640 | 509,019 |
| Events in quadrant D | 4,029,824 | 472,234 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 120 | 0 |
| B | 0 | 120 | 0 |
| C | 0 | 120 | 0 |
| D | 0 | 120 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 12585 | 3 |
| B | 0 | 12677 | 2 |
| C | 0 | 12930 | 2 |
| D | 0 | 15869 | 2 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 13 | 0 |
| B | 0 | 13 | 0 |
| C | 0 | 13 | 0 |
| D | 0 | 14 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 5850 | 10 | 0.170940% |
| B | 5850 | 56 | 0.957265% |
| C | 5850 | 63 | 1.076923% |
| D | 5850 | 235 | 4.017094% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7224 | 5851 | 0 | 0 | 0.00% | 0.00% |  |
| B | 7224 | 5851 | 20 | 20 | 0.28% | 0.34% |  |
| C | 7224 | 5851 | 46 | 46 | 0.64% | 0.79% |  |
| D | 7224 | 5851 | 194 | 194 | 2.69% | 3.32% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 15 | 169 | 280820 | 2083.59 | 662 | 648 | 134.5 |
| A | 10 | 83 | 143269 | 1060.65 | 662 | 648 | 134.5 |
| A | 13 | 6 | 15530 | 110.67 | 662 | 648 | 134.5 |
| B | 5 | 172 | 281748 | 2211.04 | 661 | 643 | 127.1 |
| B | 0 | 189 | 21640 | 165.15 | 661 | 643 | 127.1 |
| B | 4 | 81 | 17336 | 131.3 | 661 | 643 | 127.1 |
| C | 0 | 10 | 375251 | 2482.78 | 653 | 657 | 150.9 |
| C | 15 | 214 | 262891 | 1738.07 | 653 | 657 | 150.9 |
| C | 14 | 67 | 30112 | 195.23 | 653 | 657 | 150.9 |
| D | 12 | 235 | 447652 | 2899.25 | 639 | 622 | 154.2 |
| D | 13 | 249 | 414702 | 2685.55 | 639 | 622 | 154.2 |
| D | 8 | 195 | 214609 | 1387.83 | 639 | 622 | 154.2 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
