| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A11_093T01_9000005090_35557cztM0_level2.evt | modeM0/AS1A11_093T01_9000005090_35557cztM0_level2_quad_clean.evt |
| Size (bytes) | 529,755,840 | 72,066,240 |
| Size | 505.2 MB | 68.7 MB |
| Events in quadrant A | 3,670,686 | 438,422 |
| Events in quadrant B | 4,607,981 | 439,606 |
| Events in quadrant C | 3,256,082 | 464,733 |
| Events in quadrant D | 4,106,867 | 424,789 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 122 | 0 |
| B | 0 | 122 | 0 |
| C | 0 | 122 | 0 |
| D | 0 | 122 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 15201 | 3 |
| B | 0 | 17604 | 2 |
| C | 0 | 13041 | 2 |
| D | 0 | 15983 | 2 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 14 | 0 |
| B | 0 | 14 | 0 |
| C | 0 | 14 | 0 |
| D | 0 | 15 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 5926 | 28 | 0.472494% |
| B | 5926 | 781 | 13.179210% |
| C | 5926 | 64 | 1.079987% |
| D | 5926 | 330 | 5.568680% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7207 | 5927 | 11 | 11 | 0.15% | 0.19% |  |
| B | 7207 | 5927 | 530 | 530 | 7.35% | 8.94% |  |
| C | 7207 | 5927 | 52 | 52 | 0.72% | 0.88% |  |
| D | 7207 | 5927 | 254 | 254 | 3.52% | 4.29% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 15 | 169 | 872631 | 6412.74 | 673 | 658 | 136.0 |
| A | 10 | 83 | 144278 | 1056.22 | 673 | 658 | 136.0 |
| A | 9 | 143 | 41596 | 301.07 | 673 | 658 | 136.0 |
| B | 5 | 172 | 1827500 | 14857.55 | 635 | 617 | 123.0 |
| B | 15 | 85 | 108174 | 874.73 | 635 | 617 | 123.0 |
| B | 5 | 200 | 55970 | 450.17 | 635 | 617 | 123.0 |
| C | 0 | 10 | 356493 | 2321.32 | 664 | 670 | 153.3 |
| C | 15 | 214 | 265041 | 1724.7 | 664 | 670 | 153.3 |
| C | 14 | 67 | 41052 | 263.44 | 664 | 670 | 153.3 |
| D | 13 | 249 | 681183 | 4309.6 | 648 | 629 | 157.9 |
| D | 10 | 118 | 448486 | 2836.05 | 648 | 629 | 157.9 |
| D | 8 | 195 | 188958 | 1192.59 | 648 | 629 | 157.9 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
