| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1T05_026T01_9000005092_35561cztM0_level2.evt | modeM0/AS1T05_026T01_9000005092_35561cztM0_level2_quad_clean.evt |
| Size (bytes) | 460,258,560 | 96,600,960 |
| Size | 438.9 MB | 92.1 MB |
| Events in quadrant A | 3,613,208 | 632,982 |
| Events in quadrant B | 3,205,816 | 644,696 |
| Events in quadrant C | 3,379,891 | 639,995 |
| Events in quadrant D | 3,359,128 | 615,388 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 116 | 0 |
| B | 0 | 116 | 0 |
| C | 0 | 116 | 0 |
| D | 0 | 116 | 0 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 25 | 0 |
| B | 0 | 25 | 0 |
| C | 0 | 25 | 0 |
| D | 0 | 26 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 14689 | 3 |
| B | 0 | 13076 | 2 |
| C | 0 | 13435 | 2 |
| D | 0 | 13684 | 2 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 5606 | 22 | 0.392437% |
| B | 5606 | 161 | 2.871923% |
| C | 5606 | 153 | 2.729219% |
| D | 5606 | 90 | 1.605423% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7248 | 5607 | 1 | 1 | 0.01% | 0.02% |  |
| B | 7248 | 5607 | 107 | 107 | 1.48% | 1.91% |  |
| C | 7248 | 5607 | 110 | 110 | 1.52% | 1.96% |  |
| D | 7248 | 5607 | 67 | 67 | 0.92% | 1.19% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 15 | 169 | 939259 | 7120.28 | 647 | 633 | 131.8 |
| A | 10 | 83 | 143887 | 1086.7 | 647 | 633 | 131.8 |
| A | 13 | 6 | 18442 | 135.1 | 647 | 633 | 131.8 |
| B | 5 | 172 | 416640 | 3385.03 | 641 | 622 | 122.9 |
| B | 5 | 200 | 190411 | 1544.26 | 641 | 622 | 122.9 |
| B | 0 | 190 | 45982 | 369.08 | 641 | 622 | 122.9 |
| C | 0 | 10 | 415350 | 2827.02 | 634 | 640 | 146.7 |
| C | 15 | 214 | 249076 | 1693.55 | 634 | 640 | 146.7 |
| C | 3 | 233 | 82657 | 559.1 | 634 | 640 | 146.7 |
| D | 8 | 195 | 229557 | 1472.6 | 637 | 618 | 155.5 |
| D | 2 | 250 | 191794 | 1229.7 | 637 | 618 | 155.5 |
| D | 12 | 233 | 162855 | 1043.56 | 637 | 618 | 155.5 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
