| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1T05_026T01_9000005092_35571cztM0_level2.evt | modeM0/AS1T05_026T01_9000005092_35571cztM0_level2_quad_clean.evt |
| Size (bytes) | 545,304,960 | 68,667,840 |
| Size | 520.0 MB | 65.5 MB |
| Events in quadrant A | 4,916,531 | 415,876 |
| Events in quadrant B | 3,001,133 | 435,565 |
| Events in quadrant C | 3,448,725 | 430,632 |
| Events in quadrant D | 4,758,090 | 393,752 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 116 | 0 |
| B | 0 | 116 | 0 |
| C | 0 | 116 | 0 |
| D | 0 | 116 | 0 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 27 | 0 |
| B | 0 | 27 | 0 |
| C | 0 | 27 | 0 |
| D | 0 | 27 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 18684 | 3 |
| B | 0 | 12683 | 2 |
| C | 0 | 13776 | 2 |
| D | 0 | 18088 | 2 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 5773 | 31 | 0.536983% |
| B | 5773 | 96 | 1.662914% |
| C | 5773 | 109 | 1.888100% |
| D | 5773 | 410 | 7.102027% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7086 | 5774 | 0 | 0 | 0.00% | 0.00% |  |
| B | 7086 | 5774 | 68 | 68 | 0.96% | 1.18% |  |
| C | 7086 | 5774 | 72 | 72 | 1.02% | 1.25% |  |
| D | 7086 | 5774 | 328 | 328 | 4.63% | 5.68% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 15 | 169 | 2230893 | 16907.47 | 652 | 639 | 131.9 |
| A | 10 | 83 | 142181 | 1073.02 | 652 | 639 | 131.9 |
| A | 13 | 6 | 21218 | 156.01 | 652 | 639 | 131.9 |
| B | 5 | 172 | 308667 | 2430.22 | 652 | 632 | 126.8 |
| B | 5 | 200 | 79579 | 622.85 | 652 | 632 | 126.8 |
| B | 0 | 189 | 22128 | 169.59 | 652 | 632 | 126.8 |
| C | 0 | 10 | 400962 | 2679.74 | 642 | 647 | 149.4 |
| C | 15 | 214 | 259497 | 1732.76 | 642 | 647 | 149.4 |
| C | 9 | 187 | 128933 | 858.76 | 642 | 647 | 149.4 |
| D | 1 | 52 | 1711945 | 11544.72 | 614 | 597 | 148.2 |
| D | 8 | 195 | 162821 | 1094.36 | 614 | 597 | 148.2 |
| D | 12 | 233 | 153668 | 1032.61 | 614 | 597 | 148.2 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
