| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A10_071T01_9000005096_35583cztM0_level2.evt | modeM0/AS1A10_071T01_9000005096_35583cztM0_level2_quad_clean.evt |
| Size (bytes) | 390,291,840 | 53,856,000 |
| Size | 372.2 MB | 51.4 MB |
| Events in quadrant A | 2,544,612 | 331,838 |
| Events in quadrant B | 3,317,975 | 306,719 |
| Events in quadrant C | 2,932,358 | 321,998 |
| Events in quadrant D | 2,681,113 | 315,376 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 102 | 0 |
| B | 0 | 102 | 0 |
| C | 0 | 102 | 0 |
| D | 0 | 102 | 0 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 38 | 0 |
| B | 0 | 38 | 0 |
| C | 0 | 38 | 0 |
| D | 0 | 39 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 10652 | 3 |
| B | 0 | 13113 | 2 |
| C | 0 | 11622 | 2 |
| D | 0 | 11271 | 2 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 5056 | 11 | 0.217563% |
| B | 5056 | 435 | 8.603639% |
| C | 5056 | 163 | 3.223892% |
| D | 5056 | 64 | 1.265823% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 6997 | 5057 | 0 | 0 | 0.00% | 0.00% |  |
| B | 6997 | 5057 | 305 | 305 | 4.36% | 6.03% |  |
| C | 6997 | 5057 | 120 | 120 | 1.72% | 2.37% |  |
| D | 6997 | 5057 | 47 | 47 | 0.67% | 0.93% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 10 | 83 | 133156 | 1106.19 | 593 | 582 | 119.8 |
| A | 15 | 169 | 114981 | 954.54 | 593 | 582 | 119.8 |
| A | 13 | 6 | 8524 | 66.27 | 593 | 582 | 119.8 |
| B | 5 | 172 | 1014178 | 9174.21 | 562 | 547 | 110.5 |
| B | 4 | 232 | 45828 | 409.83 | 562 | 547 | 110.5 |
| B | 0 | 189 | 26271 | 232.82 | 562 | 547 | 110.5 |
| C | 0 | 10 | 443070 | 3291.47 | 569 | 574 | 134.4 |
| C | 15 | 214 | 223062 | 1654.96 | 569 | 574 | 134.4 |
| C | 10 | 49 | 33162 | 242.4 | 569 | 574 | 134.4 |
| D | 13 | 249 | 174095 | 1239.86 | 571 | 556 | 140.0 |
| D | 8 | 195 | 140855 | 1002.37 | 571 | 556 | 140.0 |
| D | 12 | 233 | 45531 | 321.33 | 571 | 556 | 140.0 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
