| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A11_106T01_9000005102_35643cztM0_level2.evt | modeM0/AS1A11_106T01_9000005102_35643cztM0_level2_quad_clean.evt |
| Size (bytes) | 831,116,160 | 63,452,160 |
| Size | 792.6 MB | 60.5 MB |
| Events in quadrant A | 14,522,987 | 238,966 |
| Events in quadrant B | 3,355,744 | 428,351 |
| Events in quadrant C | 3,579,398 | 420,206 |
| Events in quadrant D | 3,307,341 | 414,231 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 124 | 0 |
| B | 0 | 124 | 0 |
| C | 0 | 124 | 0 |
| D | 0 | 124 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 47137 | 3 |
| B | 0 | 13862 | 2 |
| C | 0 | 14285 | 2 |
| D | 0 | 13921 | 2 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 29 | 0 |
| B | 0 | 29 | 0 |
| C | 0 | 29 | 0 |
| D | 0 | 29 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 5977 | 5977 | 100.000000% |
| B | 5977 | 84 | 1.405387% |
| C | 5977 | 177 | 2.961352% |
| D | 5977 | 164 | 2.743851% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 8905 | 5979 | 5710 | 5710 | 64.12% | 95.50% |  |
| B | 8905 | 5979 | 41 | 41 | 0.46% | 0.69% |  |
| C | 8905 | 5979 | 148 | 148 | 1.66% | 2.48% |  |
| D | 8905 | 5979 | 180 | 180 | 2.02% | 3.01% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 15 | 169 | 12665030 | 139084.21 | 450 | 441 | 91.1 |
| A | 10 | 83 | 96504 | 1054.98 | 450 | 441 | 91.1 |
| A | 12 | 189 | 15996 | 170.83 | 450 | 441 | 91.1 |
| B | 5 | 172 | 584992 | 4352.05 | 684 | 666 | 134.3 |
| B | 0 | 197 | 28862 | 210.0 | 684 | 666 | 134.3 |
| B | 0 | 189 | 27695 | 201.31 | 684 | 666 | 134.3 |
| C | 0 | 10 | 632314 | 4027.79 | 670 | 675 | 156.8 |
| C | 15 | 214 | 246105 | 1565.04 | 670 | 675 | 156.8 |
| C | 9 | 187 | 88823 | 562.1 | 670 | 675 | 156.8 |
| D | 10 | 253 | 569771 | 3484.66 | 669 | 651 | 163.3 |
| D | 2 | 153 | 74935 | 454.83 | 669 | 651 | 163.3 |
| D | 13 | 249 | 50521 | 305.35 | 669 | 651 | 163.3 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
