| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1C07_001T07_9000005104_35655cztM0_level2.evt | modeM0/AS1C07_001T07_9000005104_35655cztM0_level2_quad_clean.evt |
| Size (bytes) | 710,055,360 | 70,058,880 |
| Size | 677.2 MB | 66.8 MB |
| Events in quadrant A | 11,851,411 | 329,457 |
| Events in quadrant B | 2,674,221 | 485,508 |
| Events in quadrant C | 2,856,989 | 498,320 |
| Events in quadrant D | 3,783,458 | 456,515 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 102 | 0 |
| B | 0 | 102 | 0 |
| C | 0 | 102 | 0 |
| D | 0 | 102 | 0 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 33 | 0 |
| B | 0 | 33 | 0 |
| C | 0 | 33 | 0 |
| D | 0 | 34 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 38550 | 3 |
| B | 0 | 11356 | 2 |
| C | 0 | 11470 | 2 |
| D | 0 | 14673 | 2 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 4985 | 4772 | 95.727182% |
| B | 4985 | 97 | 1.945838% |
| C | 4985 | 155 | 3.109328% |
| D | 4985 | 482 | 9.669007% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7048 | 4986 | 4652 | 4652 | 66.00% | 93.30% |  |
| B | 7048 | 4986 | 57 | 57 | 0.81% | 1.14% |  |
| C | 7048 | 4986 | 123 | 123 | 1.75% | 2.47% |  |
| D | 7048 | 4986 | 443 | 443 | 6.29% | 8.88% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 15 | 169 | 10083384 | 118553.77 | 423 | 416 | 85.0 |
| A | 10 | 83 | 106007 | 1241.52 | 423 | 416 | 85.0 |
| A | 12 | 189 | 12277 | 139.46 | 423 | 416 | 85.0 |
| B | 5 | 172 | 230478 | 2188.97 | 555 | 540 | 105.0 |
| B | 5 | 255 | 198734 | 1886.77 | 555 | 540 | 105.0 |
| B | 5 | 200 | 47854 | 450.42 | 555 | 540 | 105.0 |
| C | 0 | 10 | 433609 | 3439.63 | 549 | 553 | 125.9 |
| C | 15 | 214 | 206217 | 1633.52 | 549 | 553 | 125.9 |
| C | 15 | 208 | 40479 | 317.12 | 549 | 553 | 125.9 |
| D | 13 | 249 | 861446 | 6772.93 | 524 | 510 | 127.1 |
| D | 2 | 250 | 424309 | 3334.0 | 524 | 510 | 127.1 |
| D | 12 | 6 | 115994 | 908.51 | 524 | 510 | 127.1 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
