| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1C07_001T07_9000005104_35667cztM0_level2.evt | modeM0/AS1C07_001T07_9000005104_35667cztM0_level2_quad_clean.evt |
| Size (bytes) | 480,476,160 | 103,348,800 |
| Size | 458.2 MB | 98.6 MB |
| Events in quadrant A | 3,248,815 | 693,044 |
| Events in quadrant B | 3,912,625 | 693,089 |
| Events in quadrant C | 3,060,048 | 722,606 |
| Events in quadrant D | 3,991,867 | 671,655 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 102 | 0 |
| B | 0 | 102 | 0 |
| C | 0 | 102 | 0 |
| D | 0 | 102 | 0 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 35 | 0 |
| B | 0 | 35 | 0 |
| C | 0 | 35 | 0 |
| D | 0 | 36 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 12975 | 3 |
| B | 0 | 14813 | 2 |
| C | 0 | 12092 | 2 |
| D | 0 | 15274 | 2 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 4980 | 122 | 2.449799% |
| B | 4980 | 398 | 7.991968% |
| C | 4980 | 179 | 3.594378% |
| D | 4980 | 360 | 7.228916% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7041 | 4981 | 75 | 75 | 1.07% | 1.51% |  |
| B | 7041 | 4981 | 303 | 303 | 4.30% | 6.08% |  |
| C | 7041 | 4981 | 139 | 139 | 1.97% | 2.79% |  |
| D | 7041 | 4981 | 331 | 331 | 4.70% | 6.65% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 15 | 169 | 747150 | 6190.23 | 600 | 589 | 120.6 |
| A | 10 | 83 | 144030 | 1189.36 | 600 | 589 | 120.6 |
| A | 7 | 16 | 18468 | 148.25 | 600 | 589 | 120.6 |
| B | 5 | 172 | 886830 | 8109.51 | 589 | 574 | 109.3 |
| B | 5 | 255 | 558791 | 5107.85 | 589 | 574 | 109.3 |
| B | 3 | 112 | 86525 | 786.48 | 589 | 574 | 109.3 |
| C | 0 | 10 | 381904 | 2770.82 | 602 | 608 | 137.6 |
| C | 15 | 214 | 204005 | 1478.06 | 602 | 608 | 137.6 |
| C | 1 | 23 | 90583 | 653.84 | 602 | 608 | 137.6 |
| D | 13 | 249 | 947589 | 6620.85 | 591 | 577 | 143.0 |
| D | 10 | 234 | 205178 | 1430.43 | 591 | 577 | 143.0 |
| D | 7 | 80 | 132686 | 923.61 | 591 | 577 | 143.0 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
