| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A09_029T09_9000005138_35797cztM0_level2.evt | modeM0/AS1A09_029T09_9000005138_35797cztM0_level2_quad_clean.evt |
| Size (bytes) | 1,021,849,920 | 217,958,400 |
| Size | 974.5 MB | 207.9 MB |
| Events in quadrant A | 8,023,997 | 1,463,965 |
| Events in quadrant B | 8,016,211 | 1,462,399 |
| Events in quadrant C | 6,389,384 | 1,455,032 |
| Events in quadrant D | 7,698,364 | 1,381,679 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 248 | 0 |
| B | 0 | 248 | 0 |
| C | 0 | 248 | 0 |
| D | 0 | 248 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 31578 | 3 |
| B | 0 | 31662 | 3 |
| C | 0 | 26444 | 3 |
| D | 0 | 30526 | 3 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 36 | 0 |
| B | 0 | 36 | 0 |
| C | 0 | 36 | 0 |
| D | 0 | 37 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 12127 | 302 | 2.490311% |
| B | 12127 | 474 | 3.908634% |
| C | 12127 | 114 | 0.940051% |
| D | 12127 | 385 | 3.174734% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 15653 | 12129 | 246 | 246 | 1.57% | 2.03% |  |
| B | 15653 | 12129 | 334 | 334 | 2.13% | 2.75% |  |
| C | 15653 | 12129 | 81 | 81 | 0.52% | 0.67% |  |
| D | 15653 | 12129 | 319 | 319 | 2.04% | 2.63% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 15 | 169 | 2146355 | 7473.81 | 1443 | 1419 | 287.0 |
| A | 10 | 83 | 296753 | 1029.06 | 1443 | 1419 | 287.0 |
| A | 3 | 137 | 14114 | 44.23 | 1443 | 1419 | 287.0 |
| B | 5 | 172 | 774146 | 2928.54 | 1411 | 1378 | 263.9 |
| B | 4 | 171 | 694685 | 2627.41 | 1411 | 1378 | 263.9 |
| B | 4 | 232 | 345315 | 1303.41 | 1411 | 1378 | 263.9 |
| C | 15 | 214 | 504685 | 1594.34 | 1385 | 1395 | 315.7 |
| C | 0 | 10 | 328711 | 1036.88 | 1385 | 1395 | 315.7 |
| C | 10 | 49 | 110140 | 344.49 | 1385 | 1395 | 315.7 |
| D | 13 | 249 | 1106846 | 3323.0 | 1389 | 1354 | 332.7 |
| D | 8 | 195 | 342721 | 1026.11 | 1389 | 1354 | 332.7 |
| D | 10 | 199 | 261617 | 782.32 | 1389 | 1354 | 332.7 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
