| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A09_146T01_9000005142_35807cztM0_level2.evt | modeM0/AS1A09_146T01_9000005142_35807cztM0_level2_quad_clean.evt |
| Size (bytes) | 559,549,440 | 65,367,360 |
| Size | 533.6 MB | 62.3 MB |
| Events in quadrant A | 4,938,862 | 361,580 |
| Events in quadrant B | 3,320,550 | 420,203 |
| Events in quadrant C | 3,168,765 | 411,783 |
| Events in quadrant D | 5,116,379 | 371,001 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 122 | 0 |
| B | 0 | 122 | 0 |
| C | 0 | 122 | 0 |
| D | 0 | 122 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 18675 | 3 |
| B | 0 | 13580 | 2 |
| C | 0 | 12737 | 2 |
| D | 0 | 19096 | 2 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 32 | 0 |
| B | 0 | 32 | 0 |
| C | 0 | 32 | 0 |
| D | 0 | 32 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 5930 | 512 | 8.634064% |
| B | 5930 | 70 | 1.180438% |
| C | 5930 | 75 | 1.264755% |
| D | 5930 | 647 | 10.910624% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 9096 | 5931 | 460 | 460 | 5.06% | 7.76% |  |
| B | 9096 | 5932 | 47 | 47 | 0.52% | 0.79% |  |
| C | 9096 | 5932 | 63 | 63 | 0.69% | 1.06% |  |
| D | 9096 | 5931 | 636 | 636 | 6.99% | 10.72% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 15 | 169 | 2267193 | 17376.93 | 650 | 637 | 130.4 |
| A | 10 | 83 | 156349 | 1193.79 | 650 | 637 | 130.4 |
| A | 13 | 254 | 7218 | 50.45 | 650 | 637 | 130.4 |
| B | 5 | 172 | 192539 | 1435.75 | 691 | 673 | 133.6 |
| B | 5 | 255 | 111634 | 830.33 | 691 | 673 | 133.6 |
| B | 0 | 190 | 102528 | 762.19 | 691 | 673 | 133.6 |
| C | 15 | 214 | 250236 | 1584.04 | 675 | 677 | 157.5 |
| C | 0 | 10 | 230586 | 1459.32 | 675 | 677 | 157.5 |
| C | 10 | 49 | 42545 | 265.75 | 675 | 677 | 157.5 |
| D | 2 | 250 | 1207350 | 7614.18 | 647 | 627 | 158.5 |
| D | 13 | 249 | 699813 | 4411.72 | 647 | 627 | 158.5 |
| D | 8 | 195 | 170581 | 1072.38 | 647 | 627 | 158.5 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
