| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A11_080T01_9000005146_35868cztM0_level2.evt | modeM0/AS1A11_080T01_9000005146_35868cztM0_level2_quad_clean.evt |
| Size (bytes) | 683,910,720 | 74,217,600 |
| Size | 652.2 MB | 70.8 MB |
| Events in quadrant A | 7,874,794 | 484,935 |
| Events in quadrant B | 2,782,133 | 517,820 |
| Events in quadrant C | 3,995,485 | 476,554 |
| Events in quadrant D | 5,712,494 | 406,559 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 28 | 0 |
| B | 0 | 28 | 0 |
| C | 0 | 28 | 0 |
| D | 0 | 29 | 0 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 106 | 0 |
| B | 0 | 106 | 0 |
| C | 0 | 106 | 0 |
| D | 0 | 106 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 27218 | 128 |
| B | 0 | 11255 | 32 |
| C | 0 | 14937 | 17 |
| D | 0 | 20500 | 117 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 5137 | 1327 | 25.832198% |
| B | 5149 | 43 | 0.835114% |
| C | 5157 | 364 | 7.058367% |
| D | 5139 | 1300 | 25.296750% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7081 | 5160 | 1027 | 1027 | 14.50% | 19.90% |  |
| B | 7081 | 5162 | 23 | 23 | 0.32% | 0.45% |  |
| C | 7081 | 5165 | 347 | 347 | 4.90% | 6.72% |  |
| D | 7081 | 5162 | 1045 | 1045 | 14.76% | 20.24% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 15 | 169 | 5125514 | 40899.29 | 627 | 619 | 125.3 |
| A | 7 | 48 | 152113 | 1209.0 | 627 | 619 | 125.3 |
| A | 10 | 83 | 151294 | 1202.46 | 627 | 619 | 125.3 |
| B | 5 | 172 | 153600 | 1249.88 | 648 | 635 | 122.4 |
| B | 5 | 255 | 28199 | 225.23 | 648 | 635 | 122.4 |
| B | 12 | 111 | 14520 | 113.45 | 648 | 635 | 122.4 |
| C | 1 | 23 | 1164665 | 8165.06 | 611 | 616 | 142.6 |
| C | 15 | 214 | 212560 | 1486.65 | 611 | 616 | 142.6 |
| C | 0 | 10 | 210390 | 1471.43 | 611 | 616 | 142.6 |
| D | 2 | 250 | 2588756 | 19238.28 | 547 | 534 | 134.5 |
| D | 13 | 249 | 394062 | 2925.1 | 547 | 534 | 134.5 |
| D | 7 | 223 | 233500 | 1731.64 | 547 | 534 | 134.5 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
