| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A11_080T01_9000005146_35917cztM0_level2.evt | modeM0/AS1A11_080T01_9000005146_35917cztM0_level2_quad_clean.evt |
| Size (bytes) | 487,851,840 | 79,781,760 |
| Size | 465.3 MB | 76.1 MB |
| Events in quadrant A | 2,907,211 | 531,974 |
| Events in quadrant B | 4,553,648 | 474,415 |
| Events in quadrant C | 3,188,623 | 519,813 |
| Events in quadrant D | 3,741,145 | 493,944 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 36 | 0 |
| B | 0 | 36 | 0 |
| C | 0 | 36 | 0 |
| D | 0 | 36 | 0 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 116 | 0 |
| B | 0 | 116 | 0 |
| C | 0 | 116 | 0 |
| D | 0 | 116 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 12033 | 3 |
| B | 0 | 17131 | 2 |
| C | 0 | 12642 | 2 |
| D | 0 | 14640 | 2 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 5658 | 23 | 0.406504% |
| B | 5658 | 688 | 12.159774% |
| C | 5658 | 135 | 2.386002% |
| D | 5658 | 182 | 3.216684% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 9243 | 5660 | 9 | 9 | 0.10% | 0.16% |  |
| B | 9243 | 5659 | 500 | 500 | 5.41% | 8.84% |  |
| C | 9243 | 5660 | 92 | 92 | 1.00% | 1.63% |  |
| D | 9243 | 5660 | 124 | 124 | 1.34% | 2.19% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 10 | 83 | 172378 | 1234.29 | 677 | 665 | 139.1 |
| A | 15 | 169 | 93268 | 665.64 | 677 | 665 | 139.1 |
| A | 13 | 6 | 14575 | 99.99 | 677 | 665 | 139.1 |
| B | 5 | 172 | 1867341 | 15432.08 | 633 | 620 | 121.0 |
| B | 5 | 255 | 92062 | 755.95 | 633 | 620 | 121.0 |
| B | 0 | 213 | 39668 | 322.81 | 633 | 620 | 121.0 |
| C | 0 | 10 | 349229 | 2289.64 | 649 | 656 | 152.2 |
| C | 15 | 214 | 235680 | 1543.78 | 649 | 656 | 152.2 |
| C | 0 | 207 | 70710 | 460.16 | 649 | 656 | 152.2 |
| D | 13 | 249 | 318183 | 1980.25 | 646 | 630 | 160.4 |
| D | 8 | 195 | 289884 | 1803.78 | 646 | 630 | 160.4 |
| D | 2 | 250 | 254952 | 1585.94 | 646 | 630 | 160.4 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
