| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A11_080T01_9000005146_35931cztM0_level2.evt | modeM0/AS1A11_080T01_9000005146_35931cztM0_level2_quad_clean.evt |
| Size (bytes) | 435,919,680 | 66,957,120 |
| Size | 415.7 MB | 63.9 MB |
| Events in quadrant A | 2,694,064 | 430,854 |
| Events in quadrant B | 3,923,454 | 404,340 |
| Events in quadrant C | 2,835,923 | 423,233 |
| Events in quadrant D | 3,388,929 | 398,325 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 31 | 0 |
| B | 0 | 31 | 0 |
| C | 0 | 31 | 0 |
| D | 0 | 32 | 0 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 108 | 0 |
| B | 0 | 108 | 0 |
| C | 0 | 108 | 0 |
| D | 0 | 108 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 11106 | 3 |
| B | 0 | 14956 | 2 |
| C | 0 | 11371 | 2 |
| D | 0 | 13502 | 2 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 5290 | 16 | 0.302457% |
| B | 5290 | 480 | 9.073724% |
| C | 5290 | 82 | 1.550095% |
| D | 5290 | 142 | 2.684310% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7083 | 5291 | 4 | 4 | 0.06% | 0.08% |  |
| B | 7083 | 5291 | 352 | 352 | 4.97% | 6.65% |  |
| C | 7083 | 5291 | 61 | 61 | 0.86% | 1.15% |  |
| D | 7083 | 5291 | 103 | 103 | 1.45% | 1.95% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 10 | 83 | 166118 | 1276.07 | 634 | 624 | 129.7 |
| A | 15 | 169 | 44203 | 336.02 | 634 | 624 | 129.7 |
| A | 0 | 31 | 14396 | 106.19 | 634 | 624 | 129.7 |
| B | 5 | 172 | 1060208 | 9172.94 | 603 | 589 | 115.5 |
| B | 5 | 255 | 431398 | 3729.44 | 603 | 589 | 115.5 |
| B | 4 | 232 | 15649 | 130.37 | 603 | 589 | 115.5 |
| C | 0 | 10 | 244565 | 1716.52 | 607 | 613 | 142.1 |
| C | 15 | 214 | 221048 | 1551.04 | 607 | 613 | 142.1 |
| C | 13 | 61 | 4082 | 24.41 | 607 | 613 | 142.1 |
| D | 1 | 52 | 352784 | 2373.35 | 606 | 592 | 148.4 |
| D | 10 | 118 | 245922 | 1653.23 | 606 | 592 | 148.4 |
| D | 8 | 195 | 182707 | 1227.24 | 606 | 592 | 148.4 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
