| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1T04_069T01_9000005158_36032cztM0_level2.evt | modeM0/AS1T04_069T01_9000005158_36032cztM0_level2_quad_clean.evt |
| Size (bytes) | 500,472,000 | 79,755,840 |
| Size | 477.3 MB | 76.1 MB |
| Events in quadrant A | 2,805,495 | 525,223 |
| Events in quadrant B | 3,771,704 | 504,384 |
| Events in quadrant C | 3,296,082 | 518,848 |
| Events in quadrant D | 4,894,896 | 465,907 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 11799 | 3 |
| B | 0 | 14775 | 2 |
| C | 0 | 13193 | 2 |
| D | 0 | 18225 | 2 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 40 | 0 |
| B | 0 | 40 | 0 |
| C | 0 | 40 | 0 |
| D | 0 | 40 | 0 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 118 | 0 |
| B | 0 | 118 | 0 |
| C | 0 | 118 | 0 |
| D | 0 | 118 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 5728 | 12 | 0.209497% |
| B | 5728 | 358 | 6.250000% |
| C | 5728 | 167 | 2.915503% |
| D | 5728 | 508 | 8.868715% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 9764 | 5730 | 0 | 0 | 0.00% | 0.00% |  |
| B | 9764 | 5729 | 303 | 303 | 3.10% | 5.29% |  |
| C | 9764 | 5730 | 123 | 123 | 1.26% | 2.15% |  |
| D | 9764 | 5730 | 492 | 492 | 5.04% | 8.59% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 10 | 83 | 175381 | 1288.83 | 676 | 664 | 135.6 |
| A | 13 | 6 | 14117 | 99.24 | 676 | 664 | 135.6 |
| A | 13 | 254 | 9480 | 65.03 | 676 | 664 | 135.6 |
| B | 5 | 236 | 961633 | 7587.83 | 652 | 634 | 126.6 |
| B | 5 | 255 | 124001 | 974.07 | 652 | 634 | 126.6 |
| B | 5 | 172 | 58241 | 454.85 | 652 | 634 | 126.6 |
| C | 15 | 214 | 238526 | 1587.64 | 644 | 647 | 149.8 |
| C | 9 | 187 | 217255 | 1445.68 | 644 | 647 | 149.8 |
| C | 0 | 10 | 210773 | 1402.42 | 644 | 647 | 149.8 |
| D | 12 | 227 | 1231926 | 7917.59 | 632 | 614 | 155.5 |
| D | 12 | 235 | 484681 | 3112.65 | 632 | 614 | 155.5 |
| D | 10 | 118 | 243530 | 1562.0 | 632 | 614 | 155.5 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
