| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1T04_069T01_9000005158_36118cztM0_level2.evt | modeM0/AS1T04_069T01_9000005158_36118cztM0_level2_quad_clean.evt |
| Size (bytes) | 502,496,640 | 47,053,440 |
| Size | 479.2 MB | 44.9 MB |
| Events in quadrant A | 2,574,161 | 279,384 |
| Events in quadrant B | 3,637,556 | 273,207 |
| Events in quadrant C | 2,987,652 | 277,938 |
| Events in quadrant D | 5,668,046 | 230,906 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 10702 | 3 |
| B | 0 | 14034 | 2 |
| C | 0 | 11771 | 2 |
| D | 0 | 20420 | 2 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 30 | 0 |
| B | 0 | 30 | 0 |
| C | 0 | 30 | 0 |
| D | 0 | 31 | 0 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 106 | 0 |
| B | 0 | 106 | 0 |
| C | 0 | 106 | 0 |
| D | 0 | 106 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 5173 | 9 | 0.173980% |
| B | 5173 | 282 | 5.451382% |
| C | 5173 | 100 | 1.933114% |
| D | 5173 | 741 | 14.324377% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7267 | 5174 | 1 | 1 | 0.01% | 0.02% |  |
| B | 7267 | 5174 | 200 | 200 | 2.75% | 3.87% |  |
| C | 7267 | 5174 | 73 | 73 | 1.00% | 1.41% |  |
| D | 7267 | 5174 | 715 | 715 | 9.84% | 13.82% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 10 | 83 | 171414 | 1377.93 | 616 | 605 | 124.0 |
| A | 13 | 6 | 11919 | 91.27 | 616 | 605 | 124.0 |
| A | 9 | 143 | 8379 | 62.71 | 616 | 605 | 124.0 |
| B | 5 | 172 | 1001053 | 8766.77 | 599 | 582 | 114.1 |
| B | 5 | 236 | 99573 | 867.42 | 599 | 582 | 114.1 |
| B | 0 | 229 | 80008 | 695.98 | 599 | 582 | 114.1 |
| C | 0 | 10 | 287296 | 2076.87 | 596 | 599 | 138.0 |
| C | 15 | 214 | 220334 | 1591.79 | 596 | 599 | 138.0 |
| C | 9 | 187 | 108834 | 784.07 | 596 | 599 | 138.0 |
| D | 10 | 203 | 2526801 | 18177.1 | 572 | 556 | 139.0 |
| D | 1 | 52 | 487860 | 3506.3 | 572 | 556 | 139.0 |
| D | 10 | 118 | 151130 | 1083.43 | 572 | 556 | 139.0 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
