| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1T04_069T01_9000005158_36131cztM0_level2.evt | modeM0/AS1T04_069T01_9000005158_36131cztM0_level2_quad_clean.evt |
| Size (bytes) | 410,359,680 | 50,497,920 |
| Size | 391.3 MB | 48.2 MB |
| Events in quadrant A | 2,552,703 | 306,796 |
| Events in quadrant B | 3,020,359 | 303,267 |
| Events in quadrant C | 2,963,195 | 299,120 |
| Events in quadrant D | 3,558,390 | 275,461 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 10564 | 3 |
| B | 0 | 11933 | 2 |
| C | 0 | 11570 | 2 |
| D | 0 | 13821 | 2 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 28 | 0 |
| B | 0 | 28 | 0 |
| C | 0 | 28 | 0 |
| D | 0 | 29 | 0 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 102 | 0 |
| B | 0 | 102 | 0 |
| C | 0 | 102 | 0 |
| D | 0 | 102 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 4894 | 6 | 0.122599% |
| B | 4894 | 229 | 4.679199% |
| C | 4894 | 72 | 1.471189% |
| D | 4894 | 289 | 5.905190% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7018 | 4895 | 0 | 0 | 0.00% | 0.00% |  |
| B | 7018 | 4895 | 138 | 138 | 1.97% | 2.82% |  |
| C | 7018 | 4895 | 56 | 56 | 0.80% | 1.14% |  |
| D | 7018 | 4895 | 260 | 260 | 3.70% | 5.31% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 10 | 83 | 162554 | 1334.61 | 597 | 586 | 121.4 |
| A | 15 | 223 | 69036 | 564.03 | 597 | 586 | 121.4 |
| A | 13 | 254 | 7085 | 53.55 | 597 | 586 | 121.4 |
| B | 5 | 172 | 597457 | 5321.64 | 588 | 573 | 112.2 |
| B | 5 | 255 | 48557 | 427.81 | 588 | 573 | 112.2 |
| B | 4 | 232 | 36774 | 322.75 | 588 | 573 | 112.2 |
| C | 15 | 214 | 207904 | 1540.81 | 580 | 584 | 134.6 |
| C | 0 | 10 | 191463 | 1418.62 | 580 | 584 | 134.6 |
| C | 0 | 207 | 188388 | 1395.76 | 580 | 584 | 134.6 |
| D | 12 | 17 | 457553 | 3237.11 | 564 | 548 | 141.2 |
| D | 1 | 52 | 279254 | 1974.16 | 564 | 548 | 141.2 |
| D | 13 | 249 | 179404 | 1266.89 | 564 | 548 | 141.2 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
