| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1T05_009T01_9000005168_36187cztM0_level2.evt | modeM0/AS1T05_009T01_9000005168_36187cztM0_level2_quad_clean.evt |
| Size (bytes) | 304,223,040 | 72,336,960 |
| Size | 290.1 MB | 69.0 MB |
| Events in quadrant A | 1,921,291 | 475,884 |
| Events in quadrant B | 2,142,926 | 483,808 |
| Events in quadrant C | 2,385,865 | 487,693 |
| Events in quadrant D | 2,487,744 | 458,282 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 8384 | 2 |
| B | 0 | 9029 | 1 |
| C | 0 | 9741 | 1 |
| D | 0 | 10172 | 1 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 82 | 0 |
| B | 0 | 82 | 0 |
| C | 0 | 82 | 0 |
| D | 0 | 82 | 0 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 20 | 0 |
| B | 0 | 20 | 0 |
| C | 0 | 20 | 0 |
| D | 0 | 20 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 4041 | 9 | 0.222717% |
| B | 4041 | 40 | 0.989854% |
| C | 4041 | 52 | 1.286810% |
| D | 4041 | 106 | 2.623113% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 6014 | 4042 | 3 | 3 | 0.05% | 0.07% |  |
| B | 6014 | 4042 | 24 | 24 | 0.40% | 0.59% |  |
| C | 6014 | 4042 | 30 | 30 | 0.50% | 0.74% |  |
| D | 6014 | 4042 | 88 | 88 | 1.46% | 2.18% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 10 | 83 | 106941 | 1149.7 | 461 | 454 | 92.6 |
| A | 8 | 144 | 18787 | 197.93 | 461 | 454 | 92.6 |
| A | 9 | 143 | 11140 | 115.37 | 461 | 454 | 92.6 |
| B | 5 | 172 | 194722 | 2221.71 | 462 | 450 | 87.4 |
| B | 5 | 236 | 49444 | 560.3 | 462 | 450 | 87.4 |
| B | 5 | 255 | 45557 | 515.85 | 462 | 450 | 87.4 |
| C | 15 | 208 | 215958 | 2033.7 | 454 | 457 | 106.0 |
| C | 15 | 214 | 181153 | 1705.25 | 454 | 457 | 106.0 |
| C | 0 | 10 | 132330 | 1244.5 | 454 | 457 | 106.0 |
| D | 13 | 249 | 224519 | 2041.85 | 447 | 434 | 109.7 |
| D | 12 | 6 | 155264 | 1410.8 | 447 | 434 | 109.7 |
| D | 12 | 233 | 142980 | 1298.87 | 447 | 434 | 109.7 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
