| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A11_080T02_9000005176_36235cztM0_level2.evt | modeM0/AS1A11_080T02_9000005176_36235cztM0_level2_quad_clean.evt |
| Size (bytes) | 499,760,640 | 52,873,920 |
| Size | 476.6 MB | 50.4 MB |
| Events in quadrant A | 2,673,189 | 315,770 |
| Events in quadrant B | 4,358,327 | 304,446 |
| Events in quadrant C | 2,909,445 | 310,485 |
| Events in quadrant D | 4,819,011 | 282,555 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 30 | 0 |
| B | 0 | 30 | 0 |
| C | 0 | 30 | 0 |
| D | 0 | 31 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 11354 | 3 |
| B | 0 | 16629 | 2 |
| C | 0 | 11852 | 2 |
| D | 0 | 18121 | 2 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 114 | 0 |
| B | 0 | 114 | 0 |
| C | 0 | 114 | 0 |
| D | 0 | 114 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 5528 | 8 | 0.144718% |
| B | 5528 | 576 | 10.419682% |
| C | 5528 | 57 | 1.031114% |
| D | 5528 | 390 | 7.054993% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7321 | 5529 | 0 | 0 | 0.00% | 0.00% |  |
| B | 7320 | 5528 | 439 | 439 | 6.00% | 7.94% |  |
| C | 7321 | 5529 | 33 | 33 | 0.45% | 0.60% |  |
| D | 7321 | 5529 | 340 | 340 | 4.64% | 6.15% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 10 | 83 | 187649 | 1445.48 | 637 | 624 | 129.4 |
| A | 13 | 6 | 9709 | 70.22 | 637 | 624 | 129.4 |
| A | 13 | 254 | 9656 | 69.81 | 637 | 624 | 129.4 |
| B | 5 | 236 | 1389999 | 11870.79 | 608 | 590 | 117.0 |
| B | 5 | 172 | 202962 | 1729.02 | 608 | 590 | 117.0 |
| B | 0 | 213 | 146969 | 1250.63 | 608 | 590 | 117.0 |
| C | 0 | 10 | 248579 | 1718.0 | 619 | 623 | 144.3 |
| C | 15 | 214 | 233462 | 1613.26 | 619 | 623 | 144.3 |
| C | 13 | 61 | 4166 | 24.55 | 619 | 623 | 144.3 |
| D | 12 | 227 | 1247201 | 8413.55 | 603 | 585 | 148.2 |
| D | 12 | 6 | 616242 | 4155.14 | 603 | 585 | 148.2 |
| D | 12 | 235 | 180463 | 1214.02 | 603 | 585 | 148.2 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
