| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A10_071T37_9000005180_36255cztM0_level2.evt | modeM0/AS1A10_071T37_9000005180_36255cztM0_level2_quad_clean.evt |
| Size (bytes) | 812,960,640 | 138,153,600 |
| Size | 775.3 MB | 131.8 MB |
| Events in quadrant A | 4,435,646 | 914,167 |
| Events in quadrant B | 7,485,778 | 884,186 |
| Events in quadrant C | 5,202,931 | 896,666 |
| Events in quadrant D | 6,868,333 | 844,241 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 190 | 0 |
| B | 0 | 190 | 0 |
| C | 0 | 190 | 0 |
| D | 0 | 190 | 0 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 30 | 0 |
| B | 0 | 30 | 0 |
| C | 0 | 30 | 0 |
| D | 0 | 30 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 19215 | 3 |
| B | 0 | 28378 | 2 |
| C | 0 | 21070 | 2 |
| D | 0 | 26433 | 2 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 9293 | 23 | 0.247498% |
| B | 9293 | 815 | 8.770042% |
| C | 9293 | 178 | 1.915420% |
| D | 9293 | 349 | 3.755515% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 12279 | 9295 | 5 | 5 | 0.04% | 0.05% |  |
| B | 12279 | 9295 | 639 | 639 | 5.20% | 6.87% |  |
| C | 12279 | 9295 | 132 | 132 | 1.08% | 1.42% |  |
| D | 12279 | 9295 | 337 | 337 | 2.74% | 3.63% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 10 | 83 | 237774 | 1089.78 | 1072 | 1048 | 217.2 |
| A | 9 | 143 | 35053 | 156.54 | 1072 | 1048 | 217.2 |
| A | 13 | 254 | 16480 | 71.04 | 1072 | 1048 | 217.2 |
| B | 5 | 236 | 1437354 | 7299.07 | 1018 | 992 | 196.8 |
| B | 5 | 172 | 1117155 | 5671.94 | 1018 | 992 | 196.8 |
| B | 4 | 171 | 704882 | 3576.91 | 1018 | 992 | 196.8 |
| C | 0 | 207 | 541258 | 2222.98 | 1037 | 1042 | 243.0 |
| C | 15 | 214 | 382335 | 1569.01 | 1037 | 1042 | 243.0 |
| C | 0 | 10 | 236036 | 967.0 | 1037 | 1042 | 243.0 |
| D | 12 | 6 | 1371573 | 5385.25 | 1033 | 1005 | 254.5 |
| D | 10 | 118 | 389263 | 1525.55 | 1033 | 1005 | 254.5 |
| D | 12 | 235 | 387346 | 1518.02 | 1033 | 1005 | 254.5 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
