| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A10_071T37_9000005180_36259cztM0_level2.evt | modeM0/AS1A10_071T37_9000005180_36259cztM0_level2_quad_clean.evt |
| Size (bytes) | 197,245,440 | 45,247,680 |
| Size | 188.1 MB | 43.2 MB |
| Events in quadrant A | 1,129,697 | 311,530 |
| Events in quadrant B | 1,939,931 | 300,348 |
| Events in quadrant C | 1,223,593 | 304,729 |
| Events in quadrant D | 1,525,929 | 291,279 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 44 | 0 |
| B | 0 | 44 | 0 |
| C | 0 | 44 | 0 |
| D | 0 | 44 | 0 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 5 | 0 |
| B | 0 | 5 | 0 |
| C | 0 | 5 | 0 |
| D | 0 | 6 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 4825 | 1 |
| B | 0 | 7287 | 1 |
| C | 0 | 5001 | 1 |
| D | 0 | 6097 | 1 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 2247 | 5 | 0.222519% |
| B | 2247 | 224 | 9.968847% |
| C | 2247 | 48 | 2.136182% |
| D | 2247 | 48 | 2.136182% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 2247 | 2247 | 0 | 0 | 0.00% | 0.00% |  |
| B | 2247 | 2247 | 173 | 173 | 7.70% | 7.70% |  |
| C | 2247 | 2247 | 35 | 35 | 1.56% | 1.56% |  |
| D | 2247 | 2247 | 43 | 43 | 1.91% | 1.91% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 10 | 83 | 86247 | 1561.9 | 265 | 261 | 55.1 |
| A | 12 | 189 | 11023 | 195.49 | 265 | 261 | 55.1 |
| A | 9 | 143 | 5829 | 101.14 | 265 | 261 | 55.1 |
| B | 5 | 236 | 443584 | 8877.35 | 255 | 248 | 49.9 |
| B | 5 | 172 | 340341 | 6810.02 | 255 | 248 | 49.9 |
| B | 5 | 255 | 67717 | 1351.0 | 255 | 248 | 49.9 |
| C | 0 | 10 | 123735 | 2025.61 | 258 | 260 | 61.0 |
| C | 15 | 214 | 94293 | 1542.61 | 258 | 260 | 61.0 |
| C | 13 | 61 | 1770 | 24.77 | 258 | 260 | 61.0 |
| D | 12 | 235 | 169197 | 2615.39 | 259 | 253 | 64.6 |
| D | 12 | 6 | 153359 | 2370.2 | 259 | 253 | 64.6 |
| D | 2 | 153 | 63766 | 983.23 | 259 | 253 | 64.6 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
