| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A10_071T33_9000005186_36289cztM0_level2.evt | modeM0/AS1A10_071T33_9000005186_36289cztM0_level2_quad_clean.evt |
| Size (bytes) | 562,196,160 | 69,563,520 |
| Size | 536.2 MB | 66.3 MB |
| Events in quadrant A | 2,685,316 | 454,249 |
| Events in quadrant B | 3,665,225 | 455,503 |
| Events in quadrant C | 3,376,411 | 433,150 |
| Events in quadrant D | 6,955,202 | 407,506 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 11073 | 3 |
| B | 0 | 14256 | 2 |
| C | 0 | 13075 | 2 |
| D | 0 | 24021 | 2 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 104 | 0 |
| B | 0 | 104 | 0 |
| C | 0 | 104 | 0 |
| D | 0 | 104 | 0 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 31 | 0 |
| B | 0 | 31 | 0 |
| C | 0 | 31 | 0 |
| D | 0 | 32 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 5074 | 27 | 0.532125% |
| B | 5074 | 144 | 2.837998% |
| C | 5074 | 162 | 3.192747% |
| D | 5074 | 1802 | 35.514387% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7107 | 5075 | 10 | 10 | 0.14% | 0.20% |  |
| B | 7107 | 5075 | 100 | 100 | 1.41% | 1.97% |  |
| C | 7107 | 5075 | 153 | 153 | 2.15% | 3.01% |  |
| D | 7106 | 5074 | 1763 | 1763 | 24.81% | 34.75% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 10 | 83 | 182176 | 1437.62 | 629 | 619 | 126.3 |
| A | 9 | 143 | 44768 | 349.58 | 629 | 619 | 126.3 |
| A | 13 | 6 | 16412 | 125.05 | 629 | 619 | 126.3 |
| B | 4 | 171 | 343611 | 2882.73 | 621 | 605 | 119.0 |
| B | 0 | 155 | 306669 | 2572.26 | 621 | 605 | 119.0 |
| B | 5 | 172 | 214789 | 1800.07 | 621 | 605 | 119.0 |
| C | 0 | 10 | 447513 | 3200.44 | 604 | 612 | 139.6 |
| C | 0 | 207 | 302159 | 2159.5 | 604 | 612 | 139.6 |
| C | 15 | 214 | 210557 | 1503.5 | 604 | 612 | 139.6 |
| D | 12 | 6 | 4470087 | 37753.08 | 482 | 471 | 118.4 |
| D | 7 | 223 | 204299 | 1721.65 | 482 | 471 | 118.4 |
| D | 13 | 249 | 171297 | 1442.9 | 482 | 471 | 118.4 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
