| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A11_097T24_9000005196_36386cztM0_level2.evt | modeM0/AS1A11_097T24_9000005196_36386cztM0_level2_quad_clean.evt |
| Size (bytes) | 510,433,920 | 59,397,120 |
| Size | 486.8 MB | 56.6 MB |
| Events in quadrant A | 2,746,183 | 367,816 |
| Events in quadrant B | 3,651,810 | 354,543 |
| Events in quadrant C | 4,907,084 | 346,172 |
| Events in quadrant D | 3,774,368 | 338,191 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 112 | 0 |
| B | 0 | 112 | 0 |
| C | 0 | 112 | 0 |
| D | 0 | 112 | 0 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 17 | 0 |
| B | 0 | 17 | 0 |
| C | 0 | 17 | 0 |
| D | 0 | 18 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 11585 | 3 |
| B | 0 | 14443 | 2 |
| C | 0 | 18273 | 2 |
| D | 0 | 14949 | 2 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 5600 | 8 | 0.142857% |
| B | 5600 | 363 | 6.482143% |
| C | 5600 | 258 | 4.607143% |
| D | 5600 | 215 | 3.839286% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7183 | 5601 | 2 | 2 | 0.03% | 0.04% |  |
| B | 7183 | 5601 | 280 | 280 | 3.90% | 5.00% |  |
| C | 7183 | 5601 | 251 | 251 | 3.49% | 4.48% |  |
| D | 7183 | 5601 | 183 | 183 | 2.55% | 3.27% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 10 | 83 | 183294 | 1370.84 | 658 | 647 | 133.2 |
| A | 13 | 254 | 9110 | 63.52 | 658 | 647 | 133.2 |
| A | 3 | 137 | 7115 | 48.54 | 658 | 647 | 133.2 |
| B | 5 | 172 | 997088 | 8059.4 | 630 | 614 | 123.6 |
| B | 5 | 255 | 84036 | 674.71 | 630 | 614 | 123.6 |
| B | 15 | 85 | 30438 | 241.21 | 630 | 614 | 123.6 |
| C | 4 | 254 | 2103984 | 14431.0 | 620 | 624 | 145.8 |
| C | 15 | 214 | 239880 | 1641.52 | 620 | 624 | 145.8 |
| C | 0 | 10 | 116797 | 797.05 | 620 | 624 | 145.8 |
| D | 12 | 6 | 659295 | 4319.75 | 623 | 605 | 152.5 |
| D | 2 | 137 | 297165 | 1944.87 | 623 | 605 | 152.5 |
| D | 2 | 250 | 112172 | 731.66 | 623 | 605 | 152.5 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
