| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1T04_084T01_9000005198_36394cztM0_level2.evt | modeM0/AS1T04_084T01_9000005198_36394cztM0_level2_quad_clean.evt |
| Size (bytes) | 411,361,920 | 77,817,600 |
| Size | 392.3 MB | 74.2 MB |
| Events in quadrant A | 2,889,889 | 509,366 |
| Events in quadrant B | 3,705,673 | 502,511 |
| Events in quadrant C | 2,694,159 | 504,569 |
| Events in quadrant D | 2,824,478 | 485,079 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 11863 | 3 |
| B | 0 | 14309 | 2 |
| C | 0 | 10864 | 2 |
| D | 0 | 11756 | 2 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 104 | 0 |
| B | 0 | 104 | 0 |
| C | 0 | 104 | 0 |
| D | 0 | 104 | 0 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 24 | 0 |
| B | 0 | 24 | 0 |
| C | 0 | 24 | 0 |
| D | 0 | 25 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 5060 | 74 | 1.462451% |
| B | 5060 | 294 | 5.810277% |
| C | 5060 | 66 | 1.304348% |
| D | 5060 | 49 | 0.968379% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 6973 | 5061 | 41 | 41 | 0.59% | 0.81% |  |
| B | 6973 | 5061 | 185 | 185 | 2.65% | 3.66% |  |
| C | 6973 | 5061 | 52 | 52 | 0.75% | 1.03% |  |
| D | 6973 | 5061 | 57 | 57 | 0.82% | 1.13% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 15 | 223 | 413327 | 3470.02 | 590 | 578 | 118.9 |
| A | 10 | 83 | 178266 | 1493.84 | 590 | 578 | 118.9 |
| A | 13 | 254 | 8898 | 69.95 | 590 | 578 | 118.9 |
| B | 5 | 172 | 685343 | 6146.69 | 578 | 564 | 111.4 |
| B | 8 | 128 | 169495 | 1516.35 | 578 | 564 | 111.4 |
| B | 4 | 171 | 151788 | 1357.41 | 578 | 564 | 111.4 |
| C | 15 | 214 | 218391 | 1606.93 | 579 | 584 | 135.5 |
| C | 0 | 10 | 207978 | 1530.11 | 579 | 584 | 135.5 |
| C | 0 | 207 | 10000 | 69.47 | 579 | 584 | 135.5 |
| D | 12 | 6 | 325428 | 2300.29 | 579 | 566 | 141.2 |
| D | 2 | 249 | 88599 | 623.34 | 579 | 566 | 141.2 |
| D | 10 | 118 | 40929 | 285.8 | 579 | 566 | 141.2 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
