| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1T04_084T01_9000005198_36422cztM0_level2.evt | modeM0/AS1T04_084T01_9000005198_36422cztM0_level2_quad_clean.evt |
| Size (bytes) | 193,489,920 | 21,798,720 |
| Size | 184.5 MB | 20.8 MB |
| Events in quadrant A | 1,215,728 | 127,348 |
| Events in quadrant B | 1,699,425 | 125,302 |
| Events in quadrant C | 1,303,393 | 122,243 |
| Events in quadrant D | 1,482,246 | 117,864 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 5006 | 1 |
| B | 0 | 6587 | 1 |
| C | 0 | 5148 | 1 |
| D | 0 | 5879 | 1 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 46 | 0 |
| B | 0 | 46 | 0 |
| C | 0 | 46 | 0 |
| D | 0 | 46 | 0 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 10 | 0 |
| B | 0 | 10 | 0 |
| C | 0 | 10 | 0 |
| D | 0 | 11 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 2312 | 2 | 0.086505% |
| B | 2312 | 93 | 4.022491% |
| C | 2312 | 52 | 2.249135% |
| D | 2312 | 64 | 2.768166% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 2312 | 2312 | 1 | 1 | 0.04% | 0.04% |  |
| B | 2312 | 2312 | 50 | 50 | 2.16% | 2.16% |  |
| C | 2312 | 2312 | 29 | 29 | 1.25% | 1.25% |  |
| D | 2312 | 2312 | 55 | 55 | 2.38% | 2.38% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 10 | 83 | 88685 | 1502.7 | 289 | 283 | 58.8 |
| A | 15 | 223 | 4995 | 80.1 | 289 | 283 | 58.8 |
| A | 7 | 16 | 4305 | 68.37 | 289 | 283 | 58.8 |
| B | 5 | 172 | 312905 | 5701.88 | 283 | 277 | 54.8 |
| B | 5 | 255 | 90779 | 1650.63 | 283 | 277 | 54.8 |
| B | 4 | 232 | 73053 | 1327.33 | 283 | 277 | 54.8 |
| C | 0 | 10 | 133165 | 2047.11 | 273 | 275 | 64.9 |
| C | 15 | 214 | 99280 | 1525.13 | 273 | 275 | 64.9 |
| C | 1 | 241 | 3347 | 47.32 | 273 | 275 | 64.9 |
| D | 2 | 250 | 279172 | 4059.23 | 275 | 268 | 68.7 |
| D | 12 | 16 | 47193 | 682.96 | 275 | 268 | 68.7 |
| D | 2 | 137 | 44626 | 645.6 | 275 | 268 | 68.7 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
