| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1C07_009T01_9000005200_36424cztM0_level2.evt | modeM0/AS1C07_009T01_9000005200_36424cztM0_level2_quad_clean.evt |
| Size (bytes) | 424,497,600 | 95,042,880 |
| Size | 404.8 MB | 90.6 MB |
| Events in quadrant A | 2,561,592 | 644,518 |
| Events in quadrant B | 3,938,825 | 623,431 |
| Events in quadrant C | 2,864,614 | 628,327 |
| Events in quadrant D | 3,121,630 | 601,702 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 11182 | 3 |
| B | 0 | 15369 | 2 |
| C | 0 | 11816 | 2 |
| D | 0 | 13093 | 2 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 110 | 0 |
| B | 0 | 110 | 0 |
| C | 0 | 110 | 0 |
| D | 0 | 110 | 0 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 31 | 0 |
| B | 0 | 31 | 0 |
| C | 0 | 31 | 0 |
| D | 0 | 32 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 5435 | 9 | 0.165593% |
| B | 5435 | 316 | 5.814167% |
| C | 5435 | 77 | 1.416743% |
| D | 5435 | 120 | 2.207912% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 6988 | 5436 | 1 | 1 | 0.01% | 0.02% |  |
| B | 6988 | 5436 | 186 | 186 | 2.66% | 3.42% |  |
| C | 6988 | 5436 | 53 | 53 | 0.76% | 0.97% |  |
| D | 6988 | 5436 | 86 | 86 | 1.23% | 1.58% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 10 | 83 | 187886 | 1540.86 | 608 | 596 | 121.5 |
| A | 13 | 254 | 9219 | 70.94 | 608 | 596 | 121.5 |
| A | 13 | 6 | 8726 | 66.89 | 608 | 596 | 121.5 |
| B | 5 | 172 | 674328 | 5932.5 | 592 | 575 | 113.6 |
| B | 5 | 255 | 492273 | 4329.48 | 592 | 575 | 113.6 |
| B | 0 | 189 | 150032 | 1315.99 | 592 | 575 | 113.6 |
| C | 0 | 10 | 308678 | 2259.11 | 591 | 595 | 136.4 |
| C | 15 | 214 | 231851 | 1695.75 | 591 | 595 | 136.4 |
| C | 0 | 207 | 13159 | 92.13 | 591 | 595 | 136.4 |
| D | 12 | 6 | 225035 | 1588.36 | 590 | 575 | 141.3 |
| D | 2 | 250 | 149968 | 1057.16 | 590 | 575 | 141.3 |
| D | 2 | 137 | 105892 | 745.26 | 590 | 575 | 141.3 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
