| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1C07_009T01_9000005200_36450cztM0_level2.evt | modeM0/AS1C07_009T01_9000005200_36450cztM0_level2_quad_clean.evt |
| Size (bytes) | 400,288,320 | 61,392,960 |
| Size | 381.7 MB | 58.5 MB |
| Events in quadrant A | 2,578,759 | 391,004 |
| Events in quadrant B | 3,588,154 | 382,409 |
| Events in quadrant C | 2,847,208 | 370,506 |
| Events in quadrant D | 2,765,877 | 361,467 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 10693 | 3 |
| B | 0 | 13914 | 2 |
| C | 0 | 11379 | 2 |
| D | 0 | 11556 | 2 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 104 | 0 |
| B | 0 | 104 | 0 |
| C | 0 | 104 | 0 |
| D | 0 | 104 | 0 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 21 | 0 |
| B | 0 | 21 | 0 |
| C | 0 | 21 | 0 |
| D | 0 | 21 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 5036 | 9 | 0.178713% |
| B | 5036 | 206 | 4.090548% |
| C | 5036 | 94 | 1.866561% |
| D | 5036 | 86 | 1.707705% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7159 | 5037 | 1 | 1 | 0.01% | 0.02% |  |
| B | 7159 | 5037 | 136 | 136 | 1.90% | 2.70% |  |
| C | 7159 | 5037 | 73 | 73 | 1.02% | 1.45% |  |
| D | 7159 | 5037 | 62 | 62 | 0.87% | 1.23% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 10 | 83 | 182530 | 1491.01 | 616 | 606 | 122.0 |
| A | 13 | 254 | 8572 | 65.28 | 616 | 606 | 122.0 |
| A | 13 | 6 | 5962 | 43.89 | 616 | 606 | 122.0 |
| B | 5 | 172 | 574600 | 5155.15 | 600 | 587 | 111.3 |
| B | 5 | 255 | 349577 | 3134.24 | 600 | 587 | 111.3 |
| B | 0 | 189 | 88475 | 789.31 | 600 | 587 | 111.3 |
| C | 0 | 10 | 345118 | 2601.71 | 580 | 584 | 132.4 |
| C | 15 | 214 | 216419 | 1629.85 | 580 | 584 | 132.4 |
| C | 15 | 159 | 20446 | 149.99 | 580 | 584 | 132.4 |
| D | 13 | 249 | 241524 | 1704.28 | 587 | 572 | 141.4 |
| D | 13 | 171 | 75815 | 532.2 | 587 | 572 | 141.4 |
| D | 2 | 250 | 74149 | 520.42 | 587 | 572 | 141.4 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
