| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A09_014T01_9000005204_36463cztM0_level2.evt | modeM0/AS1A09_014T01_9000005204_36463cztM0_level2_quad_clean.evt |
| Size (bytes) | 430,614,720 | 92,928,960 |
| Size | 410.7 MB | 88.6 MB |
| Events in quadrant A | 2,807,267 | 631,140 |
| Events in quadrant B | 3,350,625 | 617,582 |
| Events in quadrant C | 3,046,656 | 614,920 |
| Events in quadrant D | 3,476,970 | 579,835 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 26 | 0 |
| B | 0 | 26 | 0 |
| C | 0 | 26 | 0 |
| D | 0 | 27 | 0 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 108 | 0 |
| B | 0 | 108 | 0 |
| C | 0 | 108 | 0 |
| D | 0 | 108 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 11506 | 3 |
| B | 0 | 13328 | 2 |
| C | 0 | 11953 | 2 |
| D | 0 | 13627 | 2 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 5297 | 14 | 0.264301% |
| B | 5297 | 109 | 2.057769% |
| C | 5297 | 96 | 1.812347% |
| D | 5297 | 180 | 3.398150% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7360 | 5298 | 0 | 0 | 0.00% | 0.00% |  |
| B | 7360 | 5298 | 74 | 74 | 1.01% | 1.40% |  |
| C | 7360 | 5298 | 61 | 61 | 0.83% | 1.15% |  |
| D | 7360 | 5298 | 138 | 138 | 1.88% | 2.60% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 10 | 83 | 196660 | 1487.01 | 666 | 656 | 131.8 |
| A | 13 | 6 | 16345 | 119.03 | 666 | 656 | 131.8 |
| A | 13 | 254 | 9908 | 70.19 | 666 | 656 | 131.8 |
| B | 5 | 172 | 286296 | 2385.52 | 647 | 632 | 119.7 |
| B | 15 | 85 | 170505 | 1418.57 | 647 | 632 | 119.7 |
| B | 5 | 255 | 114615 | 951.85 | 647 | 632 | 119.7 |
| C | 0 | 10 | 292126 | 2008.81 | 637 | 643 | 145.1 |
| C | 15 | 214 | 248626 | 1709.02 | 637 | 643 | 145.1 |
| C | 10 | 49 | 11575 | 75.34 | 637 | 643 | 145.1 |
| D | 13 | 249 | 413977 | 2710.63 | 636 | 619 | 152.5 |
| D | 12 | 128 | 125846 | 821.19 | 636 | 619 | 152.5 |
| D | 12 | 6 | 93317 | 607.88 | 636 | 619 | 152.5 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
