| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A11_049T02_9000005206_36466cztM0_level2.evt | modeM0/AS1A11_049T02_9000005206_36466cztM0_level2_quad_clean.evt |
| Size (bytes) | 377,424,000 | 68,739,840 |
| Size | 359.9 MB | 65.6 MB |
| Events in quadrant A | 2,530,228 | 443,749 |
| Events in quadrant B | 2,939,481 | 435,602 |
| Events in quadrant C | 2,762,847 | 421,787 |
| Events in quadrant D | 2,845,211 | 417,310 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 10860 | 3 |
| B | 0 | 12037 | 2 |
| C | 0 | 11422 | 2 |
| D | 0 | 11968 | 2 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 106 | 0 |
| B | 0 | 106 | 0 |
| C | 0 | 106 | 0 |
| D | 0 | 106 | 0 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 21 | 0 |
| B | 0 | 21 | 0 |
| C | 0 | 21 | 0 |
| D | 0 | 22 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 5180 | 14 | 0.270270% |
| B | 5180 | 94 | 1.814672% |
| C | 5180 | 98 | 1.891892% |
| D | 5180 | 66 | 1.274131% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7182 | 5181 | 5 | 5 | 0.07% | 0.10% |  |
| B | 7182 | 5181 | 59 | 59 | 0.82% | 1.14% |  |
| C | 7182 | 5181 | 66 | 66 | 0.92% | 1.27% |  |
| D | 7182 | 5181 | 55 | 55 | 0.77% | 1.06% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 10 | 83 | 199300 | 1663.7 | 597 | 586 | 119.4 |
| A | 13 | 254 | 9037 | 70.75 | 597 | 586 | 119.4 |
| A | 3 | 252 | 6321 | 48.02 | 597 | 586 | 119.4 |
| B | 5 | 172 | 310848 | 2767.64 | 584 | 570 | 112.1 |
| B | 5 | 255 | 125292 | 1112.5 | 584 | 570 | 112.1 |
| B | 0 | 182 | 67203 | 594.36 | 584 | 570 | 112.1 |
| C | 0 | 10 | 332840 | 2529.37 | 564 | 568 | 131.4 |
| C | 15 | 214 | 223917 | 1700.21 | 564 | 568 | 131.4 |
| C | 0 | 207 | 8883 | 63.29 | 564 | 568 | 131.4 |
| D | 13 | 249 | 187379 | 1345.61 | 571 | 557 | 138.8 |
| D | 2 | 250 | 116557 | 835.5 | 571 | 557 | 138.8 |
| D | 10 | 246 | 82663 | 591.38 | 571 | 557 | 138.8 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
