| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A11_049T04_9000005210_36487cztM0_level2.evt | modeM0/AS1A11_049T04_9000005210_36487cztM0_level2_quad_clean.evt |
| Size (bytes) | 465,459,840 | 57,548,160 |
| Size | 443.9 MB | 54.9 MB |
| Events in quadrant A | 2,754,715 | 348,418 |
| Events in quadrant B | 3,859,335 | 332,984 |
| Events in quadrant C | 2,878,550 | 340,561 |
| Events in quadrant D | 4,215,927 | 320,429 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 25 | 0 |
| B | 0 | 25 | 0 |
| C | 0 | 25 | 0 |
| D | 0 | 26 | 0 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 116 | 0 |
| B | 0 | 116 | 0 |
| C | 0 | 116 | 0 |
| D | 0 | 116 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 11790 | 3 |
| B | 0 | 15262 | 2 |
| C | 0 | 11982 | 2 |
| D | 0 | 16398 | 2 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 5716 | 6 | 0.104969% |
| B | 5716 | 301 | 5.265920% |
| C | 5716 | 34 | 0.594822% |
| D | 5716 | 233 | 4.076277% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7299 | 5717 | 1 | 1 | 0.01% | 0.02% |  |
| B | 7299 | 5717 | 214 | 214 | 2.93% | 3.74% |  |
| C | 7299 | 5717 | 16 | 16 | 0.22% | 0.28% |  |
| D | 7299 | 5717 | 173 | 173 | 2.37% | 3.03% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 10 | 83 | 204434 | 1542.16 | 653 | 642 | 132.1 |
| A | 13 | 6 | 12891 | 92.69 | 653 | 642 | 132.1 |
| A | 15 | 223 | 11378 | 81.24 | 653 | 642 | 132.1 |
| B | 5 | 172 | 1123034 | 9131.29 | 638 | 621 | 122.9 |
| B | 5 | 255 | 79601 | 642.54 | 638 | 621 | 122.9 |
| B | 0 | 190 | 66365 | 534.85 | 638 | 621 | 122.9 |
| C | 15 | 214 | 246601 | 1669.36 | 630 | 632 | 147.3 |
| C | 0 | 10 | 149068 | 1007.41 | 630 | 632 | 147.3 |
| C | 12 | 249 | 21633 | 142.53 | 630 | 632 | 147.3 |
| D | 13 | 249 | 642840 | 4227.96 | 622 | 604 | 151.9 |
| D | 1 | 52 | 556107 | 3656.98 | 622 | 604 | 151.9 |
| D | 2 | 250 | 286372 | 1881.27 | 622 | 604 | 151.9 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
