| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1T05_035T01_9000005214_36505cztM0_level2.evt | modeM0/AS1T05_035T01_9000005214_36505cztM0_level2_quad_clean.evt |
| Size (bytes) | 88,608,960 | 5,114,880 |
| Size | 84.5 MB | 4.9 MB |
| Events in quadrant A | 625,067 | 18,670 |
| Events in quadrant B | 578,469 | 18,723 |
| Events in quadrant C | 700,537 | 18,648 |
| Events in quadrant D | 705,662 | 18,236 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 2502 | 2 |
| B | 0 | 2270 | 1 |
| C | 0 | 2706 | 1 |
| D | 0 | 2861 | 1 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 22 | 0 |
| B | 0 | 22 | 0 |
| C | 0 | 22 | 0 |
| D | 0 | 22 | 0 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 20 | 0 |
| B | 0 | 20 | 0 |
| C | 0 | 20 | 0 |
| D | 0 | 20 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 1045 | 5 | 0.478469% |
| B | 1045 | 5 | 0.478469% |
| C | 1045 | 33 | 3.157895% |
| D | 1045 | 6 | 0.574163% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 2959 | 1046 | 0 | 0 | 0.00% | 0.00% |  |
| B | 2959 | 1046 | 0 | 0 | 0.00% | 0.00% |  |
| C | 2959 | 1046 | 17 | 17 | 0.57% | 1.63% |  |
| D | 2959 | 1046 | 1 | 1 | 0.03% | 0.10% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 10 | 83 | 69913 | 2328.78 | 141 | 138 | 30.0 |
| A | 7 | 3 | 5136 | 166.81 | 141 | 138 | 30.0 |
| A | 7 | 16 | 2279 | 71.46 | 141 | 138 | 30.0 |
| B | 4 | 171 | 16790 | 600.84 | 140 | 138 | 27.7 |
| B | 12 | 111 | 3141 | 108.35 | 140 | 138 | 27.7 |
| B | 11 | 111 | 2900 | 99.66 | 140 | 138 | 27.7 |
| C | 0 | 10 | 98433 | 3021.99 | 135 | 136 | 32.5 |
| C | 15 | 214 | 49543 | 1518.94 | 135 | 136 | 32.5 |
| C | 15 | 159 | 19663 | 600.33 | 135 | 136 | 32.5 |
| D | 12 | 227 | 132250 | 3954.05 | 133 | 129 | 33.4 |
| D | 11 | 176 | 31203 | 929.97 | 133 | 129 | 33.4 |
| D | 13 | 171 | 9111 | 268.81 | 133 | 129 | 33.4 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
