| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A11_089T02_9000005216_36524cztM0_level2.evt | modeM0/AS1A11_089T02_9000005216_36524cztM0_level2_quad_clean.evt |
| Size (bytes) | 425,197,440 | 77,808,960 |
| Size | 405.5 MB | 74.2 MB |
| Events in quadrant A | 2,688,649 | 516,828 |
| Events in quadrant B | 3,353,661 | 503,272 |
| Events in quadrant C | 2,819,381 | 493,616 |
| Events in quadrant D | 3,661,361 | 477,239 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 20 | 0 |
| B | 0 | 20 | 0 |
| C | 0 | 20 | 0 |
| D | 0 | 21 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 11225 | 3 |
| B | 0 | 13357 | 2 |
| C | 0 | 11560 | 2 |
| D | 0 | 14411 | 2 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 106 | 0 |
| B | 0 | 106 | 0 |
| C | 0 | 106 | 0 |
| D | 0 | 106 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 5214 | 18 | 0.345224% |
| B | 5214 | 117 | 2.243959% |
| C | 5214 | 107 | 2.052167% |
| D | 5214 | 203 | 3.893364% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7217 | 5215 | 8 | 8 | 0.11% | 0.15% |  |
| B | 7217 | 5215 | 84 | 84 | 1.16% | 1.61% |  |
| C | 7217 | 5215 | 62 | 62 | 0.86% | 1.19% |  |
| D | 7217 | 5215 | 144 | 144 | 2.00% | 2.76% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 10 | 83 | 207310 | 1672.31 | 613 | 602 | 123.6 |
| A | 9 | 143 | 37547 | 298.89 | 613 | 602 | 123.6 |
| A | 7 | 16 | 30552 | 242.3 | 613 | 602 | 123.6 |
| B | 5 | 172 | 496539 | 4316.12 | 598 | 583 | 114.9 |
| B | 5 | 255 | 156869 | 1360.1 | 598 | 583 | 114.9 |
| B | 0 | 189 | 135482 | 1173.97 | 598 | 583 | 114.9 |
| C | 0 | 10 | 306889 | 2267.46 | 579 | 583 | 135.1 |
| C | 15 | 214 | 221828 | 1637.79 | 579 | 583 | 135.1 |
| C | 2 | 48 | 22936 | 165.47 | 579 | 583 | 135.1 |
| D | 13 | 249 | 364724 | 2565.66 | 582 | 566 | 141.9 |
| D | 13 | 171 | 274920 | 1932.95 | 582 | 566 | 141.9 |
| D | 2 | 250 | 172610 | 1212.13 | 582 | 566 | 141.9 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
