| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A11_089T02_9000005216_36525cztM0_level2.evt | modeM0/AS1A11_089T02_9000005216_36525cztM0_level2_quad_clean.evt |
| Size (bytes) | 414,956,160 | 65,963,520 |
| Size | 395.7 MB | 62.9 MB |
| Events in quadrant A | 2,660,672 | 421,031 |
| Events in quadrant B | 2,990,261 | 412,030 |
| Events in quadrant C | 2,952,943 | 400,538 |
| Events in quadrant D | 3,596,448 | 385,944 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 27 | 0 |
| B | 0 | 27 | 0 |
| C | 0 | 27 | 0 |
| D | 0 | 28 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 11416 | 3 |
| B | 0 | 12318 | 2 |
| C | 0 | 12076 | 2 |
| D | 0 | 14352 | 2 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 110 | 0 |
| B | 0 | 110 | 0 |
| C | 0 | 110 | 0 |
| D | 0 | 110 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 5393 | 11 | 0.203968% |
| B | 5393 | 72 | 1.335064% |
| C | 5393 | 120 | 2.225107% |
| D | 5393 | 201 | 3.727054% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7066 | 5394 | 4 | 4 | 0.06% | 0.07% |  |
| B | 7066 | 5394 | 53 | 53 | 0.75% | 0.98% |  |
| C | 7066 | 5394 | 77 | 77 | 1.09% | 1.43% |  |
| D | 7066 | 5394 | 163 | 163 | 2.31% | 3.02% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 10 | 83 | 210066 | 1672.5 | 621 | 609 | 125.2 |
| A | 13 | 6 | 26303 | 205.16 | 621 | 609 | 125.2 |
| A | 9 | 143 | 11178 | 84.39 | 621 | 609 | 125.2 |
| B | 5 | 172 | 236084 | 1997.25 | 610 | 597 | 117.9 |
| B | 5 | 255 | 178766 | 1511.11 | 610 | 597 | 117.9 |
| B | 0 | 189 | 40306 | 336.79 | 610 | 597 | 117.9 |
| C | 0 | 10 | 365782 | 2628.2 | 589 | 595 | 138.9 |
| C | 15 | 214 | 231217 | 1659.75 | 589 | 595 | 138.9 |
| C | 10 | 49 | 47379 | 336.7 | 589 | 595 | 138.9 |
| D | 13 | 249 | 402793 | 2772.73 | 588 | 573 | 145.1 |
| D | 13 | 171 | 188544 | 1295.79 | 588 | 573 | 145.1 |
| D | 2 | 250 | 131293 | 901.13 | 588 | 573 | 145.1 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
