| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A11_089T02_9000005216_36535cztM0_level2.evt | modeM0/AS1A11_089T02_9000005216_36535cztM0_level2_quad_clean.evt |
| Size (bytes) | 445,340,160 | 80,668,800 |
| Size | 424.7 MB | 76.9 MB |
| Events in quadrant A | 3,107,966 | 533,103 |
| Events in quadrant B | 2,917,166 | 537,849 |
| Events in quadrant C | 3,776,443 | 518,070 |
| Events in quadrant D | 3,341,715 | 498,476 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 37 | 0 |
| B | 0 | 37 | 0 |
| C | 0 | 37 | 0 |
| D | 0 | 38 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 12302 | 3 |
| B | 0 | 11703 | 2 |
| C | 0 | 14493 | 2 |
| D | 0 | 13156 | 2 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 104 | 0 |
| B | 0 | 104 | 0 |
| C | 0 | 104 | 0 |
| D | 0 | 104 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 5068 | 79 | 1.558800% |
| B | 5068 | 44 | 0.868193% |
| C | 5068 | 300 | 5.919495% |
| D | 5068 | 81 | 1.598264% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7071 | 5069 | 57 | 57 | 0.81% | 1.12% |  |
| B | 7071 | 5069 | 28 | 28 | 0.40% | 0.55% |  |
| C | 7071 | 5069 | 220 | 220 | 3.11% | 4.34% |  |
| D | 7071 | 5069 | 58 | 58 | 0.82% | 1.14% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 15 | 223 | 328110 | 2481.89 | 666 | 655 | 131.9 |
| A | 10 | 83 | 191917 | 1449.64 | 666 | 655 | 131.9 |
| A | 9 | 143 | 15841 | 115.1 | 666 | 655 | 131.9 |
| B | 5 | 172 | 111071 | 897.09 | 655 | 639 | 123.1 |
| B | 15 | 54 | 61093 | 491.09 | 655 | 639 | 123.1 |
| B | 0 | 190 | 44343 | 355.03 | 655 | 639 | 123.1 |
| C | 0 | 10 | 514763 | 3614.98 | 621 | 629 | 142.2 |
| C | 10 | 49 | 388559 | 2727.61 | 621 | 629 | 142.2 |
| C | 15 | 214 | 213802 | 1498.86 | 621 | 629 | 142.2 |
| D | 2 | 250 | 157358 | 1014.86 | 643 | 627 | 154.4 |
| D | 12 | 16 | 147367 | 950.17 | 643 | 627 | 154.4 |
| D | 13 | 249 | 145997 | 941.29 | 643 | 627 | 154.4 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
