| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A11_089T02_9000005216_36550cztM0_level2.evt | modeM0/AS1A11_089T02_9000005216_36550cztM0_level2_quad_clean.evt |
| Size (bytes) | 428,650,560 | 84,556,800 |
| Size | 408.8 MB | 80.6 MB |
| Events in quadrant A | 2,788,441 | 566,417 |
| Events in quadrant B | 3,176,848 | 568,735 |
| Events in quadrant C | 3,204,090 | 556,158 |
| Events in quadrant D | 3,472,751 | 518,566 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 36 | 0 |
| B | 0 | 36 | 0 |
| C | 0 | 36 | 0 |
| D | 0 | 37 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 11180 | 3 |
| B | 0 | 12500 | 2 |
| C | 0 | 12480 | 2 |
| D | 0 | 13491 | 2 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 102 | 0 |
| B | 0 | 102 | 0 |
| C | 0 | 102 | 0 |
| D | 0 | 102 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 5003 | 15 | 0.299820% |
| B | 5003 | 77 | 1.539077% |
| C | 5003 | 173 | 3.457925% |
| D | 5003 | 177 | 3.537877% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7065 | 5004 | 1 | 1 | 0.01% | 0.02% |  |
| B | 7065 | 5004 | 40 | 40 | 0.57% | 0.80% |  |
| C | 7065 | 5004 | 117 | 117 | 1.66% | 2.34% |  |
| D | 7065 | 5004 | 146 | 146 | 2.07% | 2.92% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 10 | 83 | 194121 | 1470.84 | 662 | 651 | 131.5 |
| A | 15 | 223 | 29886 | 222.26 | 662 | 651 | 131.5 |
| A | 13 | 254 | 6916 | 47.63 | 662 | 651 | 131.5 |
| B | 5 | 255 | 352381 | 2886.94 | 646 | 632 | 121.8 |
| B | 5 | 172 | 148977 | 1217.52 | 646 | 632 | 121.8 |
| B | 15 | 85 | 37240 | 300.46 | 646 | 632 | 121.8 |
| C | 0 | 10 | 550925 | 3834.6 | 623 | 630 | 143.5 |
| C | 15 | 214 | 218510 | 1518.25 | 623 | 630 | 143.5 |
| C | 13 | 61 | 4152 | 24.54 | 623 | 630 | 143.5 |
| D | 13 | 249 | 374352 | 2475.71 | 630 | 614 | 151.0 |
| D | 2 | 250 | 146795 | 968.33 | 630 | 614 | 151.0 |
| D | 12 | 235 | 120735 | 795.7 | 630 | 614 | 151.0 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
