| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A11_049T05_9000005232_36654cztM0_level2.evt | modeM0/AS1A11_049T05_9000005232_36654cztM0_level2_quad_clean.evt |
| Size (bytes) | 384,626,880 | 89,916,480 |
| Size | 366.8 MB | 85.8 MB |
| Events in quadrant A | 2,606,844 | 607,919 |
| Events in quadrant B | 2,593,415 | 609,519 |
| Events in quadrant C | 3,167,885 | 589,806 |
| Events in quadrant D | 2,943,592 | 568,615 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 32 | 0 |
| B | 0 | 32 | 0 |
| C | 0 | 32 | 0 |
| D | 0 | 33 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 10621 | 3 |
| B | 0 | 10542 | 2 |
| C | 0 | 12300 | 2 |
| D | 0 | 11792 | 2 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 100 | 0 |
| B | 0 | 100 | 0 |
| C | 0 | 100 | 0 |
| D | 0 | 100 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 4953 | 7 | 0.141328% |
| B | 4953 | 14 | 0.282657% |
| C | 4953 | 176 | 3.553402% |
| D | 4953 | 49 | 0.989299% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7016 | 4954 | 1 | 1 | 0.01% | 0.02% |  |
| B | 7016 | 4954 | 4 | 4 | 0.06% | 0.08% |  |
| C | 7016 | 4954 | 129 | 129 | 1.84% | 2.60% |  |
| D | 7016 | 4954 | 44 | 44 | 0.63% | 0.89% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 10 | 83 | 203071 | 1643.01 | 612 | 601 | 123.2 |
| A | 9 | 143 | 20632 | 162.55 | 612 | 601 | 123.2 |
| A | 13 | 6 | 9845 | 75.01 | 612 | 601 | 123.2 |
| B | 5 | 255 | 76659 | 657.08 | 601 | 586 | 115.8 |
| B | 0 | 221 | 72684 | 622.74 | 601 | 586 | 115.8 |
| B | 0 | 199 | 48826 | 416.67 | 601 | 586 | 115.8 |
| C | 14 | 254 | 388136 | 2880.0 | 580 | 586 | 134.6 |
| C | 0 | 10 | 285182 | 2114.92 | 580 | 586 | 134.6 |
| C | 15 | 214 | 230291 | 1707.01 | 580 | 586 | 134.6 |
| D | 2 | 153 | 143512 | 996.65 | 592 | 577 | 143.4 |
| D | 12 | 6 | 122357 | 849.14 | 592 | 577 | 143.4 |
| D | 12 | 235 | 105914 | 734.49 | 592 | 577 | 143.4 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
